Relationships of logo and registered data
xn=xn1+xn2×256, yn=yn1+yn2×256
(yn1+yn2×256 bytes
(yn1+ yn2×256×8 dots
ESC FS p n m
Format: ASCII: ESC FS p
Decimal: 27
Hex: 1B
Description:
1≤n≤255
0≤m≤3
48≤m≤51 ("0"≤m≤"3")
Prints the logo of registration number n registered using the logo registration command (ESC FS q)
according to the print mode m.
ESC RS L m
Format: ASCII: ESC RS L m
Decimal: 27
Hex: 1B
Description:
0≤m≤3 48≤m≤51 ("0"≤m≤"3")
Prints all registered logos according to a print mode specified by m. Executes a printer reset after printing.
CODESOFT PL-330 User's Manual
{(xn1+xn2×256)×8} dots
d[11] d[21]
d[12] d[22]
d[x1] d[x2]
n m
28 112 n m
1C 70 n m
m
0, 48
1, 49
2, 50
3, 51 Double high/wide mode
30 76 m
1E 4C m
m
0, 48
1, 49
Logo print mode
Normal mode
Double wide mode
Double high mode
Logo print mode
Normal mode
Double wide mode
- 82 -
Dots
MSB
d[n1]
d[n2]
LSB
d[xn]
Print logo in batch
Print logo
