7.1 General

CODESOFT PL-330 supplies ESC/POS printing commands and is compatible with STAR Line Mode
printing commands.
The format is described as follows:
Command
Format: ASCII: Indicates the ASCII equivalents
Decimal: Indicates the decimal equivalents
Hex: Written in hexadecimal code
Description: The function and using instruction of that command
Example: Some examples will be listed for easier understanding

7.2 Explanation of terms

7.2.1 ESC/POS Printing Commands

BEL
Format: ASCII:
Decimal:
Hex:
Description:
Beep once in the unit of 50 milliseconds
HT
Format: ASCII:
Decimal:
Hex:
Description:
Move the print position to the next horizontal tab position
LF
Format: ASCII:
Decimal:
Hex:
Description:
Print the data in the input buffer and feed one line. If the line input buffer is empty, then it only feeds one line
without printing.
FF
Format: ASCII:
Decimal:
Hex:
Description:
Print the data in the print buffer and feeds paper to the next black mark position when black mark takes
effect.
CODESOFT PL-330 User's Manual

Chapter 7 Control Commands

BEL
7
07
HT
9
09
LF
10
OA
FF
12
OC
Print and Feed to the next black mark position
- 56 -
Function
Beep once
Horizontal tab
Print and line feed
