Programming
17-92 Position Control Selection
5.3.16 30-** Special Features
Par- Parameter description
ameter #
30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
30-21 High Starting Torque Current [%]
30-22 Locked Rotor Protection
30-23 Locked Rotor Detection Time [s]
Locked Rotor Detection Speed Error
30-24 [%]
30-25 Light Load Delay [s]
30-26 Light Load Current [%]
30-27 Light Load Speed [%]
30-8* Compatibility (I)
30-80 d-axis Inductance (Ld)
30-81 Brake Resistor (ohm)
30-83 Speed PID Proportional Gain
30-84 Process PID Proportional Gain
5.4 Remote Programming with MCT 10 Set-
up Software
Danfoss offers a software program available for developing,
storing, and transferring frequency converter programming.
The MCT 10 Set-up Software allows the user to connect a
PC to the frequency converter and perform live
programming rather than using the LCP. Also, all frequency
converter programming can be done off-line and simply
downloaded into frequency converter. Or the entire
frequency converter profile can be loaded onto the PC for
back up storage or analysis.
The USB connector or RS485 terminal are available for
connecting to the frequency converter.
MCT 10 Set-up Software with limited functionality is
available for free download at www.Danfoss.com. Enter
'MCT-10 download' in the search window.
MCT 10 Setup software with full functionality is available
on CD, part no. 130B1000.
For more information refer to the MCT 10 Set-up Software
Operating Instructions, MG10RXYY.
MG04F402
Operating Guide
[0] No operation All set-ups
Default value 4 set-up
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
25 % All set-ups
0.000 s All set-ups
0 % All set-ups
0 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit 1 set-up
ExpressionLimit All set-ups
0.100 N/A All set-ups
Danfoss A/S © 05/2016 All rights reserved.
FALSE –
Change during Conversion
operation index
TRUE -2
TRUE -1
TRUE –
TRUE -2
TRUE -1
TRUE -3
TRUE 0
TRUE 0
FALSE -6
TRUE -2
TRUE -4
TRUE -3
uint8
Type
Uint16
Uint32
Uint8
Uint8
5 5
Uint32
Uint32
Uint16
Uint16
Int32
Uint32
Uint32
Uint16
