Figure 55. Installing the filler bracket
1.
expansion card latch
3.
filler bracket
Next steps
1.
Reconnect all the cables to the expansion card.
2.
Install the cooling shroud.
3.
Follow the procedure listed in the After working inside your system section.
Related links
Installing the cooling shroud
SD vFlash card (optional)
An SD vFlash card is a Secure Digital (SD) card that plugs into the SD vFlash card slot in the iDRAC port card. It provides persistent
on-demand local storage and a custom deployment environment that enables automation of server configuration, scripts, and
imaging. It emulates USB device(s). For more information, see the Integrated Dell Remote Access Controller User's Guide at
Dell.com/idracmanuals.
Removing the optional SD vFlash card
Prerequisites
1.
Follow the safety guidelines listed in the Safety instructions section.
2.
Locate the SD vFlash card slot at the back of the chassis.
2.
slot
4.
guide pin
