COULTER® EPICS® XL™ Flow Cytometer
COULTER EPICS XL-MCL™ Flow Cytometer
SYSTEM II™ Software
PN 4237296CA (September 2010)
Beckman Coulter, Inc.
250 S. Kraemer Blvd.
Brea, CA 92821
CYTOMETER
READY
FS
SS
LASER
ON
AUX
FL1
SAMPLE FLOW
FL2
LOW
MED HIGH
FL3
FL4
®
TM
Special Procedures
and Troubleshooting
