PN LXLAI-IM-10AB
February 2014
Beckman Coulter, Inc.
250 S. Kraemer Blvd.
Brea, CA 92821 U.S.A.
Instructions For Use
ProteomeLab XL-A/XL-I
Protein Characterization System
