Adjustment > Adjustment Item > Overview
Adjustment Item

Overview

This finisher has no adjustment items.
Sensor detection check and motor operation check can be performed using the DIP switch
(SW1), push switch (SW2), and LED (LD1) on the finisher controller PCB.
LD1
5
Adjustment > Adjustment Item > Overview
SW2
SW1
F-5-1
5-2
5-2
