4
Parts Replacement and Cleaning Procedure > Main Units > Removing the Staple Unit
3) Remove the 4 screws and disconnect the connector, and then remove the grate-shaped guide.
x2

Removing the Staple Unit

1) Removing the front cover
2) Remove the 2 screws and disconnect the 2 connectors, and then remove the staple unit.
(Refer to page 4-7)
4
Parts Replacement and Cleaning Procedure > Main Units > Removing the Staple Unit
x2
x2
x1
F-4-21
4-11
x2
F-4-20
4-11
