Icons and Text in the Display

All functions and settings available to the user are shown as icons and text in the display.
The icons and text in the display indicate functions and settings to which you have access.
The display normally displays date and time, the Owner ID and handset number. The Owner
ID can manually be set by the user.
Menu
Figure 3. Example of a display configuration in idle mode.
The top row (Status bar) is used for icons which give the user information about signal
strength, missed call, new message, phone lock, key lock, sound off, time and battery status.
This row is always visible in all screens.
The next row (Header bar) displays the current date, headset connection, Bluetooth
connection, and system connection.
The next rows (Active area) are used for information such as the name of the system to
which the handset is connected to. A user identity provided from the system and/or an
Owner ID can also be displayed if configured in the Settings menu. This is also the area for
dialog window text. For example "missed calls" or to confirm an action.
The bottom row (Soft key bar) is used for Soft keys which can be used as shortcuts for
functions in the handset. See
The (Scroll bar) is placed to the right of the "Active area". It becomes visible when a menu
screen has more than six menus, or if the complete text in a message cannot be displayed
on the screen simultaneously.
8 April 2016 / Ver. M
Status bar
11:00
Header bar
05/12/2009
System A
Active area
Scroll bar
709040
Soft key bar
2.4.7 Soft Keys on page 12.
