Appendix B. Bluetooth Barcode Reader

B.1 Introduction
If the handset's hardware supports Bluetooth (a icon
battery lid), a Bluetooth barcode reader can be used.
Note: The Bluetooth barcode reader requires that the license dependent Bluetooth Data
Profile feature is enabled. See Configuration Manual, Ascom d62 DECT Handset, 92639GB.
Bluetooth supported functions:
• Pair the handset with it's Bluetooth barcode reader
• Choose which device to use when scanning barcodes
• Scan barcode(s) and send the information to a handset/system
B.2 Icon
See 2.3 Icons and Text in the Display
B.3 Bluetooth Barcode Readers
A number of Bluetooth barcode readers for different work situations have been tested
together with the handset. Refer to the Ascom Wireless Extranet Website for a list of
verified Bluetooth barcode readers.
Since the Bluetooth supports the Bluetooth 2.0 standard, other Bluetooth barcode reader
may also work although not verified by Ascom.
Note: The Bluetooth barcode reader may have more or less functions than described here,
refer to the Manual for the Bluetooth barcode reader.
B.4 Operation
Step between the menus with the navigation key
pressing the Soft key "Select".
B.4.1 Enable Bluetooth
To enable the Bluetooth function enter
select "Enable".
B.4.2 Pair and Connect a Bluetooth Barcode Reader
Before a barcode reader can be used a connection (pairing) between the barcode reader and
the handset must be established.
1 Place the Bluetooth barcode reader and the handset next to each other.
2 Enable Bluetooth, see
3 Put the Bluetooth barcode reader in pairing mode, see the user manual for the
Bluetooth barcode reader.
4 On the handset enter
new". A dialog "Put barcode reader in pairing mode" is displayed.
5 Press "OK". It now searches for a Bluetooth barcode reader for connection.
8 April 2016 / Ver. M
on page 7.
in the handset menu, select Bluetooth and
A.5.1Enable Bluetooth.
in the menu, select "Bluetooth" > "Barcode reader", "Add
TD 92477EN
is printed on the label under the
. Confirm each menu selection by
