Rack Charger

The Charging Rack is used for charging several handsets, to synchronize parameters, and
for software download.
See Installation and Operation Manual, CR3 Charging Rack, TD 92480EN.
3.3

Icons and Text in the Display

All functions and settings available to the user are shown as icons and text in the display.
The icons and text in the display indicate functions and settings to which you have access.
The display normally displays date and time, the Owner ID and handset number. The
Owner ID can manually be set by the user.
Select
Figure 3. Example of a display configuration in standby mode.
The top row (Status bar) is used for icons which give the user information about signal
strength, missed call, phone lock, key lock, sound off, time and battery status. This row is
always visible in all screens.
The next row (Header bar) displays the current date, headset connection, and system
connection.
The next rows (Active area) are used for information such as the name of the system to
which the handset is connected to. A user identity provided from the system and/or an
Owner ID can also be displayed if configured in the Settings menu. This is also the area for
dialog window text, for example "missed calls" or "received messages".
The bottom row (Soft key bar) is used for Soft keys that are located just beneath the
display. See
The (Scroll bar) is placed to the right of the "Active area". It becomes visible when a menu
screen has more than six menus.
Icons
21 June 2012 / Ver. G
Manual, DC4 Desktop Charger, TD92481GB.
Status bar
11:00
Header bar
01/12/2009
System A
Active area
Scroll bar
709040
Soft key bar
3.4.6 Soft Keys on page 12.
"Signal strength" icon is visible in the upper left corner. The staples
shown in display depends on the signal strength.
TD 92582EN
9
