Procedure Call - ASCOM d62 User Manual

User Manual
Ascom d62 DECT Handset
9

Procedure Call

When configuring the functions Call services, In Call menu, Contacts, or a shortcut or service
to the Phone call function, the data added in these functions is static. When entering the
data for the function to be used, a variable or character U can be entered that allows the
user to enter additional numerical characters before calling the number or sending the data
to a system.
NOTE: The Call services and In call menu features require configuration in PDM/Device
Manager. The "service" feature is applicable for d62 Messenger and d62 Protector only.
See the following example for more information.
Example of configuration:
A user wants to create a service with the Phone call function. The PBX requires that a prefix
must be added to a phone number. In this case, the user can pre-program the prefix and
then enter the applicable phone number when using the Phone call function.
1 Press "Menu", or the confirmation button.
2 Select "Services".
3 Select "Add new".
4 In the Name field, enter "Call no." and press the "OK" soft key.
5 Select the function "Phone call".
6 In the Number field, enter the prefix to be used followed by the character "U". In this
case, the text string is as follows *21*U. The character U represents an Enter number
dialog where the user can enter the phone number.
7 Press "Save".
When using the function, an Enter number dialog appears, see
"123" (or selects a contact with this number by pressing
number *21*123 is dialled. Note that no call is established before the user presses "OK",
that is, post-dial.
OK
Figure 12. Enter number dialog.
8 April 2016 / Ver. M
13:00
Services
Enter number:
123
Back
TD 92477EN
figure 12. If the user enters
) and presses "OK", the
73
