Mobile Data; Send Mobile Data; Send Mobile Data With A Prefix; Send Data With Bluetooth Barcode Reader - ASCOM d62 User Manual

User Manual
Ascom d62 DECT Handset
Redisplay the Message and Terminate the Call
1 Press
by the redisplayed text message.

6.13 Mobile Data

NOTE: This is a system dependent feature for d62 Messenger and d62 Protector only.

6.13.1 Send Mobile Data

User entered data can be sent from the handset by pressing a pre-programmed Hot key or
Soft key, or selecting a Service. Mobile data can be used for opening a door, starting/
stopping a machine etc. The data can either be predefined, or entered after the Hot key/Soft
key is pressed or Service is selected.
The data can be predefined when programming the Soft/Hot key or Service, see
Soft Keys on page 58,

6.13.2 Send Mobile Data with a Prefix

Mobile data with a prefix is sent from the handset by entering data and then pressing a pre-
programmed Hot key or Soft key or select a Service. Mobile data with prefix can be used to
send information to an application in the system.
The prefix is predefined by the user when programming the Hot/Soft key or Service,
Define Soft Keys

6.14 Send Data with Bluetooth Barcode Reader

The handset can be configured to receive data from a Bluetooth barcode reader and then
send the data to another destination. When the handset receives data, it is automatically
transmitted to the destination and is not stored in the handset. A dialog window "Message
sent" is displayed.
For more information about configuration, see the Configuration Manual for the Ascom d62
DECT Handset. See also
manual for the Bluetooth barcode reader.

6.15 Voicemail

NOTE: This feature is only available if configured in the system.

6.15.1 Receive a Voicemail

When receiving a voicemail, the content of the voicemail notification is displayed
automatically on the screen, and is also indicated by the "Voicemail message" icon
the status bar.
If the content of the notification is displayed, press "Call" to dial the voicemail. If "Close" is
selected, the voicemail can be dialled by a long press on digit key "1" in standby mode, or
from the Inbox menu.
Information is stored in the "Messaging" inbox (see
voicemail messages have been listened to.
8 April 2016 / Ver. M
. The call is terminated and the ongoing call summary details are replaced
8.3.2 Define Hot Keys
on page 58 on page 46 or
Pair and Connect Bluetooth Barcode Reader
on page 59, or 8.4.1 Add Services
8.3.2 Define Hot Keys on page 59.
on page 48, and user
3.4 Messaging on page 17) until all
TD 92477EN
8.3.1 Define
on page 60.
8.3.1
in
43
