User Manual
Ascom d62 DECT Handset
8 If needed, enter PIN code, see user manual for the Bluetooth headset. Press "OK".
The dialog Successful pairing appears if the pairing process was successful. The
Bluetooth headset is also connected indicated by the icon
Tip: The headset button can be configured with a specific function, such as post-dial, dial
last called number, or dial a predefined number. See Configuration Manual, Ascom d62 DECT
Handset, TD 92639EN for more information.
Pair and Connect Bluetooth Barcode Reader
NOTE: This is a license dependent feature, and requires that the handset's hardware
supports Bluetooth.
In order to use a Bluetooth barcode reader, it must first be paired with the handset. It is only
needed to pair it once. A paired Bluetooth barcode reader is connected automatically and
this is indicated by the icon
See also 6.14 Send Data with Bluetooth Barcode Reader
1 Set the Bluetooth barcode reader in pairing mode, see the user manual for the
Bluetooth barcode reader.
2 Enable Bluetooth, see
3 Select "Bluetooth".
4 Select "Barcode reader".
5 Select "Add new". A dialog window "Put barcode reader in pairing mode" is displayed.
6 Press "OK". It now searches for a Bluetooth barcode reader for connection.
7 When Bluetooth barcode reader is found, press "Pair".
8 If needed, enter PIN code, see user manual for the Bluetooth barcode reader. Press
"OK".
The dialog Successful pairing appears if the pairing process was successful. The
Bluetooth barcode reader is also connected. This is indicated by the icon
the barcode reader.
8.1.2

Headset

In order to achieve optimal audio quality with the different headset types, it is
recommended to select the corresponding headset profile.
The default setting is microphone on a boom, that is, the audio is optimized for using a
headset with microphone on a boom. The headset profile can be changed in the menu by do
as follows:
1 Select "Headset".
2 Select the corresponding headset profile from list, that is, "Mic on boom", "Mic on
cable", "Hearing protection", or "Customized headset profile" (only visible if the
headset profile has been configured in the PDM/Device Manager).
3 Press "Select".
8 April 2016 / Ver. M
in front of the barcode reader.
Enable Bluetooth Connection.
TD 92477EN
in front of the headset.
on page 43.
in front of
48
