Select the title of a column to sort the table according to the values in the column.
The Team members page provides the following information:
 Number of controllers: Number of controllers that are configured as members of the
team.
 Detected: Status light icon indicating if the controller has been discovered on the
network.
 Green: The controller has been discovered on the network and is listed on the
Overview > Discovered controllers page, where more information is provided
about the controller.
 Red: The controller was manually added to the team, but it has never been
discovered and successfully joined the team.
Controller name: Name assigned to the controller. Select the name to configure

controller settings.
 Serial number: Serial number assigned to the controller. Select the name to configure
controller settings.
 Product: Product name of the controller.

Team configuration

Once a team is operational, configuration and management of VSCs and controlled APs
occurs via the team manager, using the VSC and Controlled APs options in the Network
Tree. Configuration of these elements is the same as during non-teamed operation. Refer to
Chapter 5: Working with VSCs
information.
Configuration settings for the team members however, can occur at three different levels:
 Team: These are global configuration settings that are defined using the management
tool on the team manager and are synchronized on all team members. Most team
configuration settings fall into this category.
 Controller: The team manager provides a separate configuration menu for each
controller in a team, including the team manager. This allows individual settings specific
to a controller to be defined.
 Local: The management tool on each controller can also be accessed directly to define
any options that are not directly configurable using the team manager. For example,
some connectivity settings must be defined locally on each controller.
and
Chapter 6: Working with controlled APs
Controller teaming

Team configuration

for more
8-17
