Console ports

Overview

Overview
Console port and cable information for the MSM7xx controllers is provided as follows:
Product
MSM710, MSM730, MSM750
MSM760, MSM765zl

MSM710 Console port

The MSM710 provides a DB-9 (female) Console (serial) port connector. The DB-9 connector
(DCE) has pin assignments as follows:
To connect to a computer, use a standard (straight through) serial cable (male-to-female).

MSM730 Console port

The MSM730 provides a DB-9 (male) Console (serial) port connector (DTE). The DB-9
connector has pin assignments as follows:
B-2
Information to use
Relevant section below
The provided Installation and Getting Started Guide.
