Creating a T3, VT, or AUG Controller
Where STS_number is the virtual T3 or VT controller. Enter a value from 1 to 12.
Use the no form of the command to remove a T3 or VT controller.
In the following example, STS-1 number 1 is defined as a T3 line and controller T3 number 2/0/0.1 is
generated:
Router(config)# controller sonet 2/0/0
Router(config-controller)# path 1 controller t3
In the next example, STS-1 number 1 is defined as a VT line and a VT controller 2/0/0.1 is generated:
Router(config)# controller sonet 2/0/0
Router(config-controller)# path 1 controller vt
Designating an STM-4 Port as an AU-3 or AU-4-TUG-3 Controller under SDH
Framing
When the 4-port STM-1 line card is configured for SDH framing, you can use the aug controller
command to specify the mode of operation for an STM-4 port as an AU-3 controller or an AU-4-TUG-3
controller. This command creates 12 subcontrollers of the designated type, which you can then configure
like any other controller.
[no] aug controller <au-3|au-4-tug-3>
Where au-3 and au-4-tug-3 designate the type of controller. Enter a value from 1 to 12.
Use the no form of the command to remove an AU-3 or AU-4-TUG-3 controller.
The format of the name for these controllers requires you to add a subport extension to the SONET
controller name. The subport extension is different for AU-3 and AU-4-TUG-3 controllers.
AU-3 Controller
For an AU-3 controller, the syntax is:
controller au-3 <slot>/<subslot>/<port>.<AU-3#>
For example, the following command Uses AU-3 controller #3 on port 0 of a line card in slot 2.
Router(config-controller)# controller au-3 2/0/0.3
AU-4-TUG-3 Controller
For an AU-4-TUG-3 controller, the syntax is:
Router(config-controller)# controller au-4-tug-3 <slot>/<subslot>/<port>.<AU-4#>/<TUG-3#>
The twelve AU-4-TUG-3 controllers created on an SDH-framed SONET port are based on the same
Note
higher order path and do not operate independently from one another. In other words, when you
"shutdown" any AU-4-TUG-3 controller, the other two controllers on the same SDH-framed SONET
port are also shut down.
For example, the following command uses TUG-3 #3 on AU-4 of port 0 of an 4-port STM-1 line card in
slot 2.
Router(config-controller)# controller au-4-tug-3 2/0/0.1/3
