Clearing a Jammed Sheet, Fed Manually
•
If the paper is jammed by the Ejection Guide
Remove the jammed paper from the Output Tray.
After removing the paper, make sure there are no other
scraps of paper in the printer.
4
Press the OK button.
Clearing a Jammed Sheet, Fed Manually
Clearing a Jammed Sheet, Fed Manually
If a sheet you have fed manually becomes jammed, "Paper jam" is shown on the Display Screen of the Control Panel.
Remove the jammed paper as follows.
1
Press the OK button.
2
Remove the jammed paper.
If paper is jammed inside the Top Cover
•
1.
Open the Top Cover and manually move the
Carriage to the side.
614
•
Do not move the Carriage over jammed paper. This may damage the Printhead.
Important
iPF6400SE
User's Guide
