iPF6400SE
8
With the nozzles facing down and the metal contacts
toward the back, insert the Printhead into the Carriage.
Carefully push the printhead firmly into the Carriage,
ensuring that the nozzles and metal contacts do not
touch the carriage.
9
Pull the Printhead Fixer Cover down toward the front to
lock the Printhead in place.
10
Push the Printhead Fixer Lever toward the back of the
printer until it clicks.
User's Guide
Replacing the Printhead
583
