Device
P
PE2
CE2
Configuration Thought
1. Configure the IP addresses of loopback1 and physical interface on CE1. Establish
EBGP neighborhood between CE1 and PE1. Advertise the loopback address in BGP.
2. Configure the IP addresses of loopback 1 and vlan2 on PE1. Configure a VRF
called test1.
Configure OSPF and advertise the network segment 10.10.0.0/16 in OSPF. Establish
MPBGP neighborhood between PE1 and PE2, and enable VPNv4. Establish EBGP
neighborhood between PE1 and CE1. Enable LDP on the interface vlan2.
3. Configure the IP addresses of vlan2 and vlan3 on P. Configure OSPF and advertise
the network segment 10.10.0.0/16 in OSPF. Enable LDP on the interfaces vlan2 and
vlan3.
4. Configure the IP addresses of loopback 1 and vlan3. Configure a VRF called test1.
Bind the interface vlan4 to the test1 and configure IP address. Configure OSPF and
advertise the network segment 10.10.0.0/16 in OSPF. Establish MPBGP neighborhood
between PE1 and PE2, and enable VPNv4. Establish OSPF neighborhood between
CE2 and PE2. Enable LDP on the interface vlan3.
5. Configure the IP addresses of loopback1 and vlan4. Configure OSPF and advertise
the network segments 10.10.10.2 and loopback200.1.1.1 in OSPF.
Configuration Commands
CE1 configuration,
CE1(config)#interface loopback1
CE1(config-if-loopback1)#ip address 100.1.1.1 255.255.255.0
CE1(config-if-loopback1)#exit
CE1(config)#interface vlan1
CE1(config-if-vlan1)#ip address 10.1.1.2 255.255.255.0
CE1(config-if-vlan1)#exit
CE1(config)#router bgp 200
CE1(config-bgp)#network 100.1.1.0 255.255.255.0
CE1(config-bgp)#neighbor 10.1.1.1 remote-as 100
PE1 configuration,
PE1(config)#ip vrf test1
PE1(config-vrf-test1)#rd 100:1
PE1(config-vrf-test1)#address-family ipv4
SJ-20150114102049-016|2015-03-10 (R1.0)
Interface Name
gei-0/1/1/4 (vlan2)
gei-0/1/1/5 (vlan3)
gei-0/1/1/6 (vlan3)
gei-0/1/1/7 (vlan4)
gei-0/1/1/8 (vlan4)
Bind the interface vlan1 to the test 1 and configure IP address.
1-19
Chapter 1 MPLS L3VPN Configuration
Address
10.10.12.2/24
10.10.23.2/24
10.10.23.3/24
10.10.10.1/24
10.10.10.2/24
