Motherboard Features

CPU
•
Single Intel® E3-1200 v5, 6th Gen Core i3, Pentium, and Celeron series processor in an LGA1151 socket
Memory
•
Integrated memory controller supports up to 64 GB of DDR4 ECC UDIMM 2133MHz memory in four DIMM slots.
DIMM Size
•
4GB, 8GB, 16GB at 1.2V
Note 1: Memory speed support depends on the processors used in the system.
Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
•
Intel® PCH C236
Expansion Slots
•
One (1) PCI Express 3.0 X2 (IN X4) slot (PCH Slot4)
•
One (1) PCI Express 3.0 X8 slot (CPU Slot6)
Network
•
Intel® X550 10G Ethernet Network Controller
BaseBoard Management Controller (BMC)
•
ASpeed AST 2400 Baseboard Controller (BMC) supports IPMI 2.0
•
One (1) Dedicated IPMI LAN located on the rear IO back panel
Graphics
•
Graphics controller via ASpeed 2400 BMC
•
Intel IGD
I/O Devices
•
Serial (COM) Port
•
SATA 3.0
•
RAID (PCH)
•
SAS 3.0 (X11SSH-CTF only)
•
RAID (LSI3008)
Note: The table above is continued on the next page.
Motherboard Features
•
One (1) Fast UART 16550 port on the I/O back panel
•
One (1) serial-port header
•
Eight (8) SATA 3.0 ports supported by Intel PCH (I-SATA 0-7)
•
RAID 0, 1, 5, 10
•
Eight (8) SAS 3.0 connections via LSI3008 with two mini-SAS HD (SAS 0-7)
•
RAID 0, 1, 10
