X11SSH-CTF/TF User's Manual
Peripheral Devices
•
Two (2) USB 2.0 ports on the rear I/O panel (USB 0/1)
•
Two (2) internal USB 2.0 headers with two (2) USB connections on the motherboard for front access (USB 2/3, 4/5)
•
Two (2) USB 3.0 ports on the rear I/O panel (USB 6/7)
•
One (1) internal USB 3.0 header with two (2) USB connections on the motherboard for front access (USB 9/10)
•
One (1) Type-A USB 3.0 connector for front access (USB 8)
BIOS
•
128 Mb SPI AMI BIOS
•
ACPI 4.0a, SMBIOS 2.7, BIOS rescue hot-key, Plug-and-Play (PnP), SPI dual/quad speed support, Riser card auto
detection support, RTC (Real TIme Clock) wakeup, Dual-Boot Block
Power Management
•
Power button override mechanism
•
Power-on mode for AC power recovery
•
Wake-on-LAN
•
Intel® Intelligent Power Node Manager 3.0 (available when the Supermicro Power Manager [SPM] is installed and a
special power supply is used. See the note on page 21.)
•
Management Engine (ME)
•
ACPI Power Mangement
System Health Monitoring
•
Onboard voltage monitoring for +3.3V, +5V, +3.3V standby, +5V standby, +/-12V, VBAT, HT, Memory, PCH Temp., System
Temp., Memory Temp.
•
CPU switch phase voltage regulator
•
CPU Thermal Trip support
•
Status monitor for speed control
•
Status monitor for on/off control
•
CPU Thermal Design Power (TDP) support of up to 80W (See Note 1 on next page.)
Fan Control
•
Fan status monitoring via IPMI connections
•
Dual cooling zone
•
Low-noise fan speed control
•
Pulse Width Modulation (PWM) fan control
System Management
•
Trusted Platform Module (TPM) support
•
PECI (Platform Environment Control Interface) 2.0 support
•
UID (Unit Identification)/Remote UID
•
System resource alert via SuperDoctor® 5
•
SuperDoctor® 5, Watch Dog, NMI
•
Chassis intrusion header and detection
Note: The table above is continued on the next page.
Motherboard Features
SM Flash UEFI BIOS
®
