SMBus to PCI Slots
Jumpers JI C1 and JI
2 2
PCI-E/PCI slots. Both jumpers must be set to the same setting (JI
JI C2 controls the clock). The default setting is Disabled.
2
BMC Enabled
JPB1 allows you to enable or disable the BMC (Baseboard Management Control) chip and
the onboard IPMI connection. This jumper is used together with the IPMI settings in the BIOS.
After the BMC is disabled, IPMI health monitoring and remote management functions are no
longer supported.
