Quick Reference Table

Jumper Description
JBR1 BIOS Recovery
JBT1 CMOS Clear
JI C1/JI C2 SMB to PCI-E Slots Enable/Disable
2 2
JPB1 BMC Enabled
JPCK1 LANCONF Flash
JPG1 VGA Enable/Disable
JPME2 Manufacturing Mode
JPS1 SAS 3.0 Enable/Disable (X11SSH-CTF only)
JPSAS1 SAS HDD Enable/Disable (X11SSH-CTF only)
JPTG1 10Gb LAN Enable/Disable
JVRM1 VRM SMB Clock (to BMC or PCH)
JVRM2 VRM SMB Data (to BMC or PCH)
JWD1 Watch Dog
LED Description
LEDBMC BMC Heartbeat LED
LEDPWR Onboard Power LED
LEDS1 SAS Activity LED (X11SSH-CTF only)
LE1 UID LED
LE3 M.2 LED
Connector Description
BT1 Onboard Battery
COM1/COM2 COM Port/COM Header
FAN1 ~ FAN5, FANA System/CPU Fan Headers (FAN1: CPU Fan)
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0 ~ I-SATA7 Intel® PCH SATA 3.0 Ports
I-SGPIO1/I-SGPIO2 Serial Link General Purpose I/O Headers
J24 M.2 PCI-E 3.0 X4 Slot
JD1 Power LED/Speaker Header (Pins 1-3: Power LED, Pins 4-7: Speaker)
JF1 Front Control Panel Header
JIPMB1 4-pin BMC External I2C Header (for an IPMI Card)
JL1 Chassis Intrusion Header
JOH1 Overheat LED Header
JPI C1 Power Supply SMBbus I
2
JPWR1 24-pin ATX Power Connector
JPWR2 12V 8-pin Processor Power Connectors
JSAS1 Eight SAS 3.0 Ports (X11SSH-CTF only)
Note: Table is continued on the next page.
Status
Blinking Green: BMC Normal
Solid Green: Power On
Blinking Green: SAS Active, Red: SAS Error
Solid Blue: Unit Identified
Blinking Green: Active
C Header
2
13
Chapter 1: Introduction
Default Setting
Pins 1-2 (Normal)
Open (Normal)
Pins 2-3 (Disabled) (Default)
Pins 1-2 (Enabled)
Pins 2-3 (Disabled) (Default)
Pins 1-2 (Enabled)
Pins 1-2 (Normal)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled) (Default)
Pins 1-2 (Enabled)
Pins 1-2 (BMC, Normal)
Pins 1-2 (BMC, Normal)
Pins 1-2 (Reset)
