Standalone
MediaPort 200
Application Setup
The MediaPort 200 can integrate seamlessly into a variety of applications. This section
contains instructions on how to set up the MediaPort 200 for the following application:
•
This application is one of many configurations for the Standalone MediaPort and was
designed to give a fundamental understanding of the MediaPort 200 in a common
application.

Overview

This section contains a general discussion of MediaPort 200 inputs and outputs and their
intended uses when the MediaPort 200 is used as a standalone device. All of the principles
described here are used in the application setup procedure that follows.
ATTENTION: Ensure the MediaPort 200 is set to Standalone audio mode in PCS before

Video Input and Output

HDMI Input

The HDMI Input can be fed from a camera, a computer, an HDMI switcher, or other HDMI
source. The HDMI source can be a video conference or document camera without audio.
The source can also be a PC or switcher output that includes embedded audio. If the HDMI
input includes microphone audio, the HDMI audio should be muted.

HDCP-Compliant HDMI Loop-Out

The HDCP-Compliant Loop-Out can be used as a local monitor output or can be fed into
a hardware video codec. If the local monitor connected is not HDCP compliant, the HDCP
compliance setting can be changed via PCS (see
panel (see
Mode (HDMI Loop Output)
Application 1 — Standalone MediaPort 200
General Settings Tab
beginning setup (see
selecting Standalone audio mode).
Output Configuration Menu
on page 123).
MediaPort 200 • Standalone MediaPort 200 Application Setup
on page 59 for more information about
HDMI Loop on page 42), the front
on page 73) or SIS Commands (see HDCP
83
