Exhaust Pipe Bolts And Muffler Mounting Bolts; Air Cleaner - HYOSUNG 2010 ST7 Service Manual

2-7 PERIODIC MAINTENANCE
EXHAUST PIPE BOLTS AND
MUFFLER MOUNTING BOLTS
Inspect Interval
Tighten Initial 1,000 km and Every 6,000 km thereafter.
Tighten the exhaust pipe bolts ①, and muff ler
mounting bolts ② to the specified torque.
Exhaust pipe bolt
: 18 ~ 28 N m (1.8 ~ 2.8 kgf m)
Muffler mounting bolt
: 20 ~ 25 N m (2.0 ~ 2.5 kgf m)

AIR CLEANER

Inspect Interval
Clean Every 3,000 km,
Replace Every 12,000 km.
If the air cleaner is clogged with dust, intake resis-
tance will be increased, with a resultant decrease in
power output and an increase in fuel consumption.
Check and clean the air cleaner element in the fol-
lowing manner :
● Remove the air cleaner cover ④ by loosening the
two air cleaner cover screws ③.
● Loosen the four air cleaner element screws ⑤.
● Remove the air cleaner element
②
.
①
Front Cylinder
Rear Cylinder
③
❺
①
④
❺
