Options - Icom ic-718 Instruction Manual

IC-PW1/EURO HF + 50 MHz 1 KW
AH-4 HF + 50 MHz
AUTOMATIC
ANTENNA TUNER
Specially designed to tune a long wire
antenna for portable or mobile HF op-
eration. The PTT tuner start function
provides simple operation.
• Input power rating: 120 W
SM-30
DESKTOP MICROPHONE
Includes a low frequency cut function.
SP-23
EXTERNAL SPEAKER
4 audio fi lters, headphone jack, can
be connected to 2 transceivers.
• Input impedance: 8 ø
• Max. input power: 4 W
LINER AMPLIFIER
Full-duty 1 kW linear am-
plifi er including an auto-
matic antenna tuner. Has
automatic tuning and
band selection capabil-
ity. Full break-in (QSK)
operation is possible.
The amplifi er/power sup-
ply unit and the remote
control unit can be sep-
arated.
AH-2b
ANTENNA ELEMENT
A 2.5 m long an-
tenna element for
mobile operation
with the AH-4.
• Frequency
coverage:
3.5–28 MHz bands
with the AH-4
SM-50
DESKTOP MICROPHONE
Unidirectional, dynamic microphone
for base station operation. Includes
[UP]/ [DOWN] switches, a low cut
switch and mic gain control.
PS-126
DC POWER SUPPLY
• Output voltage: 13.8 V DC
• Max. output current: 25 A

OPTIONS

AT-180 HF + 50 MHz
AUTOMATIC
ANTENNA TUNER
Fully automatic antenna tuner with
preset memories for each 100 kHz.
Unique "Automatic tuner on " func-
tion is available. See p. 51 for AT-180
specifi cations.
AH-740
AUTOMATIC TUNING ANTENNA
High performance, auto-
matic high-speed tuning an-
tenna.
• Frequency coverage
With 1.54 m whip antenna:
2.5 MHz–29.9999 MHz
With AH-5NV (NVIS kit):
2.2 MHz–29.9999 MHz
HM-36
HAND MICROPHONE
Hand microphone equipped with [UP]/
[DOWN] switches.
Same as supplied.
FL-222 and FL-257
455 kHz
FILTERS
• FL-222: 1.8 kHz/–6 dB (SSB narrow)
• FL-257: 3.3 kHz/–6 dB (SSB wide)
12
55
