SUB -Z E R O B U ILT-IN U SE & C AR E
ICE M AK E R OPE R AT ION
The ice maker in your Sub-Zero freezer is fully
automatic and has been tested at the factory. To
start making ice, activate the key pad on the
Control Center.
The ice maker system will not shut off if the ice
bucket is not in place.
When removing the ice bucket for an extended
period, deactivate the ice maker by depressing
the key pad on the Control Center.
IC E PR OD UCTI ON
The ice maker is designed to produce enough ice
for normal family use. The timing of ice-making
cycles will vary depending on load conditions,
door openings and room temperature. On
average, you can expect a cycle of ice (eight
cubes per cycle) every two hours.
The ice maker operates on water pressure of 2.1
bar to 6.9 bar. In some cases, a reverse osmosis
water filter system may not be able to maintain
the minimum pressure.
IMPORTANT NOTE: If ice is not used regularly it
tends to fuse together. To avoid this, empty and
replace the ice in the container as needed.
ACCE SSORI E S
Optional acces-
sories are available
through your
Sub-Zero dealer. To
obtain local dealer
information, visit
our website,
subzero.com.
10
M AX IC E FEA T URE
The Max Ice feature increases the rate of ice pro-
duction for times where you need more than
normal. The increased ice production will last for
24 hours, at which time it will return to the
normal production level. You can expect about a
40% increase in ice production when this feature
is turned on.
To initiate the Max Ice feature, press the
pad on the Control Center so that the indi-
cator is visible in the display panel. Refer to the
illustration below.
To turn off the Max Ice feature, simply press the
key pad and the unit will return to normal
ice production.
Max Ice
Key Pad
Max Ice key pad Air purification cartridge
A IR P U R IF I CAT IO N SY STE M
All Sub-Zero Built-In models (except Model
ICBBI-36F) include an advanced air purification
system. This system reduces bacteria, odors,
and even ethylene gas, which causes premature
ripening in fruits and vegetables. The air purifi-
cation cartridge has been factory installed and is
located inside the refrigerator, on the right-hand
side of the back wall.
The air purification cartridge will last for approxi-
key
mately one year. The indicator will flash in
the Control Center display panel when it needs
to be replaced. To replace the cartridge, grab the
outside cover from the bottom and pull it for-
ward. It will flip up and expose another flap and
the cartridge. Refer to the illustration below. Pull
the flap forward from the top, which will cause
the cartridge to pop out of position. Remove the
cartridge.
To replace, put the new cartridge into place, with
the connector pointing down. Once in place,
close the flap until you hear a click. Then flip
down the outside cover until it closes against the
wall.
Once the air purification cartridge has been
replaced, press the keypad on the Control
Center for 5 seconds. This will reset the air purifi-
cation indicator and will no longer be displayed.
R E PL AC E ME N T C AR T R I D GE S
Replacement air purification cartridges can be
ordered by contacting your Sub Zero dealer.
CAUTION
LAMP CONTAINS MERCURY
Manage in accordance with disposal
laws.
IMPORTANT NOTE: The warranty for the air
purification cartridge supplied with the unit only
covers defects in materials or workmanship and
not replacement due to normal use.
