Installation Information
Finished Rough Opening Specifications (36" All Refrigerator and All Freezer Models)
INSTALLATION SPECIFICATIONS
All Refrigerator / All Freezer Models—
Overlay (non-flush inset) and Stainless Steel
Model ICBBI-36R
Model ICBBI-36RG
Model ICBBI-36F
Dimensions are for finished rough openings.
Models ICBBI-36R and ICBBI-36RG will not
require the water line connection.
INSTALLATION SPECIFICATIONS
All Refrigerator / All Freezer Models—
Flush Inset Application
Model ICBBI-36R
Model ICBBI-36RG
Model ICBBI-36F
Dimensions are for finished rough openings.
Models ICBBI-36R and ICBBI-36RG will not
require the water line connection.
7025630 - Revision A - April, 2012
International Built-In
International Built-In
* ANTI-TIP BRACKET MUST NOT
INTERFERE WITH WATER LINE.
REFER TO INSTALLATION
INSTRUCTIONS FOR COMPLETE
DETAILS.
EXTEND WATER LINE APPROX
A
914 mm FROM BACK WALL.
902 mm
902 mm
610 mm
902 mm
OPENING
* ANTI-TIP BRACKET MUST NOT
INTERFERE WITH WATER LINE.
REFER TO INSTALLATION
INSTRUCTIONS FOR COMPLETE
DETAILS.
**ASSUMES 19 mm PANEL
THICKNESS.
A
B
EXTEND WATER LINE APPROX
902 mm
965 mm
914 mm FROM BACK WALL.
902 mm
965 mm
610 mm
OPENING
902 mm
965 mm
665 mm
FLUSH INSET
TOP VIEW
610 mm
OPENING
DEPTH
DEPTH
2127 mm
OPENING
HEIGHT
SIDE VIEW
TOP VIEW
610 mm
OPENING
DEPTH
6 mm
56 mm **
DEPTH
56
mm **
FLUSH INSET
DETAIL
DEPTH
56
mm
2127 mm
2134
mm
OPENING
FLUSH
HEIGHT
INSET
HEIGHT
32
mm
SIDE VIEW
2-4
Series
Series
(ICBBI)
(ICBBI)
152
457 mm *
mm
13 mm
WATER LINE
OUTLINE OF
OVERLAY
OR STAINLESS
SHUT-OFF
STEEL MODEL
VALVE
178
E
mm
LOCATE
ELECTRICAL
152
WITHIN
mm
SHADED AREA
A
OPENING WIDTH
1918 mm
LOCATE WATER SUPPLY
WITHIN SHADED AREA
152
457 mm
mm
76 mm
W
FRONT VIEW
152
457 mm *
mm
13 mm
WATER LINE
665 mm
FLUSH INSET
OUTLINE
DEPTH
OF FLUSH INSET
APPLICATION WITH
SHUT-OFF
19 mm PANEL
VALVE
178
E
LOCATE
mm
ELECTRICAL
WITHIN
152
mm
SHADED AREA
6
mm
610 mm
OPENING
1918 mm
DEPTH
32
mm
A
32
OPENING WIDTH
mm
B
FLUSH INSET WIDTH
LOCATE WATER SUPPLY
WITHIN SHADED AREA
152
457 mm
mm
76 mm
W
FRONT VIEW
