BUILT-IN DESIGN GUIDE
STAINLESS FLUSH INSET INSTALLATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICBBI-36F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sub-Zero ICBBI-36F

Summary of Contents for Sub-Zero ICBBI-36F

  • Page 1 BUILT-IN DESIGN GUIDE STAINLESS FLUSH INSET INSTALLATION...
  • Page 2 Features and specifications are subject to change at any time without notice. Visit subzerowolf.com.au for the most up-to-date information.

  • Page 3: Built-In Refrigeration

    914 mm 914 mm 914 mm Built-In Refrigeration. For the built-in line, Sub-Zero designers and engineers took a fresh look at everything, 2134 2134 inside and out. Exterior refinements include redesigned grilles and lower-profile hinges. Inside, new technology in food preservation makes the built-in line nothing short of revolutionary.

  • Page 4: Specifications

    HEIGHT DIMENSIONS ± SIDE-BY-SIDE MODELS 102 mm ICBBI-36S ICBBI-42S ICBBI-42SD ICBBI-48S ICBBI-48SD 60 mm MODELS ICBBI-36R AND ICBBI-36F Shipping weights and overall dimensions are based on stainless steel models. For flush inset applications, add 13 mm to door clearance dimensions.

  • Page 5: Over-And-Under Models

    Built-In Refrigeration subzero.com/specs Over-and-Under Models OVERALL DIMENSIONS 762 mm 610 mm 914 mm 610 mm 2134 2134 1289 1289 13 mm 13 mm HEIGHT DIMENSIONS ± 606 mm HEIGHT DIMENSIONS ± 606 mm 102 mm 102 mm 60 mm 60 mm MODEL ICBBI-30U MODEL ICBBI-36U...

  • Page 6: Side-By-Side Models

    Built-In Refrigeration Side-by-Side Models OVERALL DIMENSIONS 914 mm 610 mm 1067 mm 610 mm 2134 2134 1873 1873 13 mm 13 mm HEIGHT DIMENSIONS ± 606 mm HEIGHT DIMENSIONS ± 606 mm 102 mm 102 mm 60 mm 60 mm MODEL ICBBI-36S MODELS ICBBI-42S AND ICBBI-42SD Overall dimensions are based on stainless steel models.
  • Page 7 Built-In Refrigeration subzero.com/specs Side-by-Side Models OVERALL DIMENSIONS 1219 mm 610 mm 2134 1873 13 mm 606 mm HEIGHT DIMENSIONS ± 102 mm 60 mm MODELS ICBBI-48S, ICBBI-48SD & ICBBI-48SID...

  • Page 8: Planning Information

    Built-In Refrigeration subzero.com/specs Planning Information ELECTRICAL REQUIREMENTS PLUMBING REQUIREMENTS International models from the factory designed without a For built-in models with an automatic ice maker, a transformer require a 220-240 V AC, 50/60 Hz electrical pressure limiting valve and 5 meters of fl exible 6mm supply, fused at the correct rating for the unit.
  • Page 9 Built-In Refrigeration subzero.com/specs Stainless Flush Inset Application It is necessary to consider the following points when planning for a fl ush inset application: • The fl ush inset depth is 56 mm deeper than the standard opening depth. • The fl ush inset width is 46 mm wider than the standard opening width.

  • Page 10: Flush Inset Installation

    Built-In Refrigeration 620 mm TOP VIEW minimum minimum OPENING CLEAT FLUSH Built-In Models DEPTH INSET TO CLEAT DEPTH 76 mm FLUSH INSET INSTALLATION typical 56 mm TOP VIEW 23 mm 675mm 620 mm 620 mm minimum minimum TOP VIEW minimum FLUSH DEPTH minimum...

  • Page 11: Dual Installation

    WITHOUT FILLER STRIP FILLER STRIP REQUIRED FILLER STRIP REQUIRED FILLER STRIP REQUIRED FILLER STRIP REQUIRED authorized Sub-Zero dealer. WITHOUT FILLER STRIP FILLER STRIP REQUIRED FILLER STRIP REQUIRED * Dual installations without a fi ller strip can only be accom- plished using two units with opposite hinges as shown in illustration A below.
