  • Page 1 INTERNATIONAL DESIGN GUIDE...
  • Page 2 Contents Built-In Refrigeration ......3 PRO 48 Refrigeration ......34 Integrated Refrigeration .

  • Page 3: Built-In Refrigeration

    Built-In Refrigeration. For the built-in line, Sub-Zero designers and engineers took a fresh look at everything, inside and out. Exterior refinements include redesigned grilles and lower-profile hinges. Inside, new technology in food preserva- tion makes the built-in line nothing short of revolutionary.

  • Page 4: Table Of Contents

    Built-In Refrigeration Built-In Models All Refrigerator / All Freezer Models SPECIFICATIONS OVERALL DIMENSIONS Interior Capacity R (L) F (L) 914 mm 610 mm ALL REFRIGERATOR / ALL FREEZER MODELS ICBBI-36R ICBBI-36F OVER-AND-UNDER MODELS ICBBI-30U ICBBI-36U SIDE-BY-SIDE MODELS 2134 ICBBI-36S ICBBI-42S 1873 ICBBI-42SD ICBBI-48S...

  • Page 5: Over-And-Under Models

    Built-In Refrigeration subzero.com/specs Over-and-Under Models OVERALL DIMENSIONS 762 mm 610 mm 914 mm 610 mm 2134 2134 1289 1289 13 mm 13 mm HEIGHT DIMENSIONS ± 606 mm HEIGHT DIMENSIONS ± 606 mm 102 mm 102 mm 60 mm 60 mm MODEL ICBBI-30U MODEL ICBBI-36U...

  • Page 6: Side-By-Side Models

    Built-In Refrigeration Side-by-Side Models OVERALL DIMENSIONS 914 mm 610 mm 1067 mm 610 mm 2134 2134 1873 1873 13 mm 13 mm HEIGHT DIMENSIONS ± 606 mm HEIGHT DIMENSIONS ± 606 mm 102 mm 102 mm 60 mm 60 mm MODEL ICBBI-36S MODELS ICBBI-42S AND ICBBI-42SD Overall dimensions are based on stainless steel models.
  • Page 7 Built-In Refrigeration subzero.com/specs Side-by-Side Models OVERALL DIMENSIONS 1219 mm 610 mm 2134 1873 13 mm HEIGHT DIMENSIONS ± 606 mm 102 mm 60 mm MODELS ICBBI-48S AND ICBBI-48SD...

  • Page 8: Icbbi-36S

    Built-In Refrigeration Built-In Models STANDARD INSTALLATION TOP VIEW 610 mm OPENING DEPTH 610 mm 2127 mm OPENING DEPTH OPENING OPENING WIDTH HEIGHT SIDE VIEW FRONT VIEW IMPORTANT NOTE: If two units are installed side by side, Opening Width refer to pages 21–22 for dual standard installations. ICBBI-36R and ICBBI-36F 902 mm Stainless steel models are ready to install out of the box.
  • Page 9 A saddle valve kit (4200880) is avail- For all built-in models, the electrical supply should be able through your authorized Sub-Zero dealer. The water located within the shaded area shown in the illustration. line must not interfere with installation of the anti-tip Follow local codes and ordinances when installing the brackets.
  • Page 10 Do not exceed overlay panel dimensions, as this could spacer panel and a 6 mm backer panel. Depending on cause damage to panels and the Sub-Zero unit. your cabinet manufacturer, this could also be one panel routed for different dimensions.
  • Page 11 Built-In Refrigeration subzero.com/specs Overlay Panels ICBBI-30U / ICBBI-36U Model ICBBI-30U Model ICBBI-36U REFRIGERATOR REFRIGERATOR Overlay Panel 762 mm 1273 mm Overlay Panel 1273 Spacer Panel 740 mm 1253 mm Spacer Panel 1253 Backer Panel 756 mm 1268 mm Backer Panel 1268 FREEZER FREEZER...

  • Page 12: Icbbi-42S

    Built-In Refrigeration Overlay Panels ICBBI-36S / ICBBI-42S / ICBBI-48S ICBBI-48SD Model ICBBI-36S Models ICBBI-48S and ICBBI-48SD REFRIGERATOR REFRIGERATOR Overlay Panel 510 mm 1772 mm Overlay Panel 730 mm 1772 mm Spacer Panel 487 mm 1751 mm Spacer Panel 708 mm 1751 mm Backer Panel 503 mm...
  • Page 13 Built-In Refrigeration subzero.com/specs Flush Inset Application It is necessary to consider the following points when FLUSH INSET INSTALLATION planning for a flush inset application: 19 mm STANDARD INSTALLATION WITH PANEL • The flush inset depth is 56 mm deeper than the standard opening.

  • Page 14: Icbbi-36F

    Built-In Refrigeration Built-In Models FLUSH INSET INSTALLATION TOP VIEW 610 mm 610 mm TOP VIEW DEPTH OPENING FLUSH TO CLEAT FLUSH DEPTH INSET CLEAT INSET TO CLEAT DEPTH UNIT WITH CLEAT DEPTH 19 mm PANEL 76 mm typical DETAIL A 56 mm 56 mm 6 mm...

  • Page 15: Flush Inset Panels

    FLUSH INSET SPACER PANEL PANEL Do not exceed flush inset panel dimensions, as this could cause damage to panels and the Sub-Zero unit. BACKER PANEL Flush Inset Panel Requirements MAX WEIGHT PER PANEL All Flush Inset Models 23 kg...
  • Page 16 Built-In Refrigeration Flush Inset Panels PANEL OFFSETS TOP VIEW TOP VIEW DOOR / DRAWER / GRILLE Illustrations A–F provide panel offsets and reveals for all built-in models in a flush inset application. Refer to the chart below for reference to the illustrations relating to DOOR DOOR BACKER...
  • Page 17 Built-In Refrigeration subzero.com/specs Flush Inset Panels ICBBI-30U / ICBBI-36U Model ICBBI-30U Model ICBBI-36U REFRIGERATOR REFRIGERATOR Flush Inset Panel 787 mm 1273 mm Flush Inset Panel 940 mm 1273 mm Spacer Panel 740 mm 1253 mm Spacer Panel 892 mm 1253 mm Backer Panel 756 mm 1268 mm...

  • Page 18: Icbbi-48Sd

    Built-In Refrigeration Flush Inset Panels ICBBI-36S / ICBBI-42S / ICBBI-48S ICBBI-48SD Model ICBBI-36S Models ICBBI-48S and ICBBI-48SD REFRIGERATOR REFRIGERATOR Flush Inset Panel 522 mm 1772 mm Flush Inset Panel 743 mm 1772 mm Spacer Panel 487 mm 1751 mm Spacer Panel 708 mm 1751 mm Backer Panel...
  • Page 19 Built-In Refrigeration subzero.com/specs Dispenser For overlay and flush inset models, mounting placement of MODEL ICBBI-48SD the refrigerator door handle must assure proper access to The refrigerator door panel must include a cut-out to the glasswell and adequate clearance under the handle. accommodate the dispenser glasswell and bezel.
  • Page 20 IMPORTANT NOTE: The use of side panels may change authorized Sub-Zero dealer. the width of your rough opening. The side panel will need to be a minimum of 610 mm deep and 13 mm thick.

  • Page 21: Dual Installation

    12 kg require a dual installation kit, avail able through your MIN PANEL THICKNESS authorized Sub-Zero dealer. If you are installing two units Overlay and Flush Inset Panels 16 mm side by side in a flush inset application, refer to page 23.
  • Page 22 Built-In Refrigeration Dual Installation STANDARD INSTALLATION TOP VIEW 610 mm OPENING DEPTH TWO UNITS WITH 19 mm PANEL 610 mm 2127 mm OPENING DEPTH OPENING OPENING WIDTH HEIGHT SIDE VIEW FRONT VIEW IMPORTANT NOTE: A dual installation kit will be required Opening Widths for this installation.
  • Page 23 Dual flush inset panels and dual installation kits are avail- able through your authorized Sub-Zero dealer. Refer to pages 25–26 for dual flush inset panel specifications and page 27 for information on dual installation kits.
  • Page 24 Built-In Refrigeration Dual Installation FLUSH INSET INSTALLATION TOP VIEW 610 mm DEPTH 610 mm TOP VIEW FLUSH TO CLEAT OPENING INSET FLUSH DEPTH 32 mm CLEAT DEPTH INSET TWO UNITS WITH CLEAT TO CLEAT 19 mm DEPTH PANEL 76 mm typical DETAIL A 56 mm...
  • Page 25 Grille Bottom / Door Top Door Bottom / Drawer Top DOOR Drawer Bottom 16 mm DRAWER Do not exceed flush inset panel dimensions, as this could cause damage to panels and the Sub-Zero unit. SIDE VIEW SIDE VIEW Illus. E Illus. F...
  • Page 26 Built-In Refrigeration Dual Installation—Flush Inset Panels ICBBI-30U / ICBBI-36U ICBBI-30U ICBBI-36U REFRIGERATOR REFRIGERATOR Flush Inset Panel 775 mm 1273 mm Flush Inset Panel 927 mm 1273 mm Spacer Panel 740 mm 1253 mm Spacer Panel 892 mm 1253 mm Backer Panel 756 mm 1268 mm Backer Panel...
  • Page 27 Built-In Refrigeration subzero.com/specs Dual Installation Kit INSTALLATION WITH DUAL WIDE GRILLE INSTALLATION WITH INDIVIDUAL GRILLES This kit will replace the existing grilles that ship with the This kit is available for those who choose to utilize the units and span the entire width of both units. The kit individual grilles that ship with each unit.
  • Page 28 Accessories These optional accessories are avail able through your STANDARD HANDLES authorized Sub-Zero dealer. For local dealer information, Refer to the chart below for standard handle lengths visit the find a showroom section of our website, and the stud spacing of tubular and pro handles used on subzero.com.
  • Page 29 Built-In Refrigeration subzero.com/specs Overlay Panel Thickness FULL-SCALE TEMPLATE Overlay and flush inset panels must be a minimum of 16 mm thick to support mounting the handle. Panel thickness does not include backer and spacer panel. Mount handle close to the opening edge of the door. DEPTH OF TUBULAR AND PRO HANDLES 32 mm...
  • Page 30 Built-In Refrigeration Overlay Application FULL-SCALE TEMPLATE 606 mm OVERALL WIDTH OF UNIT TO REAR OF UNIT 25 mm THICK PANEL 19 mm THICK OVERLAY PANEL (TYPICAL) 6 mm BACKER PANEL 0 mm 25 mm DOOR OPENING 90° TOP VIEW SCALE...
  • Page 31 Built-In Refrigeration subzero.com/specs Flush Inset Application 610 mm FULL-SCALE TEMPLATE TO BACK WALL For panels thicker than 19 mm, a 90° door stop may be required to prevent interference with adjacent cabinets. 32 mm 56 mm ASSUMES 19 mm FLUSH INSET PANEL THICKNESS 25 mm...
  • Page 32 Built-In Refrigeration FILLER STRIP 32 mm APPROX PROFILE OF DOOR STAINLESS STEEL WRAPPED CLOSED DOOR AND HANDLE DOOR Dual Installation—Standard OPEN 110° FULL-SCALE TEMPLATE Typical overlay or stainless steel dual installation with filler strip at maximum 110° door opening. Depending on panel thickness, a 90°...
  • Page 33 Built-In Refrigeration subzero.com/specs FILLER STRIP 38 mm 13 mm 19 mm PROFILE OF FLUSH INSET PANEL DOOR AND TUBULAR HANDLE CLOSED DOOR Dual Installation—Flush Inset OPEN 110° FULL-SCALE TEMPLATE Typical flush inset dual installation with filler strip at maximum 110° door opening.

  • Page 34: Pro 48 Refrigeration

    PRO 48 Refrigeration PRO 48 Refrigeration. Freshness finds unmistakable expression in the Sub-Zero PRO 48. A 363 kg monument to food preservation—equal parts sculpted metal design statement and culinary secret weapon. Its vast interior, like its bold exterior, is crafted of stainless steel. The PRO 48 is available with or without a glass door and may be either built in or freestanding.

  • Page 35: Pro 48 Models

    PRO 48 Refrigeration subzero.com/specs PRO 48 Models OVERALL DIMENSIONS 1219 mm 657 mm 2134 1070 102 mm 13 mm HEIGHT DIMENSIONS ± 767 mm 533 mm SPECIFICATIONS Capacity / Weight INTERIOR CAPACITY R (L) F (L) ICB648PRO and ICB648PROG SHIPPING WEIGHT ICB648PRO ICB648PROG 60 mm...
  • Page 36 PRO 48 Refrigeration PRO 48 Models STANDARD AND FLUSH BUILT-IN INSTALLATIONS TOP VIEW OPENING DEPTH OPENING OPENING OPENING DEPTH HEIGHT WIDTH SIDE VIEW FRONT VIEW IMPORTANT NOTE: For standard built-in installations, the Opening Dimensions Standard Flush face frame of the unit will extend 51 mm beyond cabinetry. Opening Width 1206 mm 1219 mm...
  • Page 37 Do not use self-piercing valves. A saddle valve kit ELECTRICAL REQUIREMENTS (4200880) is avail able through your authorized Sub-Zero International models from the factory designed without a dealer. The water line must not interfere with installation of transformer require a 220-240 V AC, 50/60 Hz electrical the anti-tip brackets.
  • Page 38 PRO 48 Refrigeration Accessories These optional accessories are avail able through your authorized Sub-Zero dealer. For local dealer information, visit the find a showroom section of our website, subzero.com. • Freestanding kit, which contains two stainless steel side panels and top lid.

  • Page 39: Integrated Refrigeration

    Integrated Refrigeration. With custom cabinet fronts and hardware, Sub-Zero invented integrated drawers and tall units that disappear into the decor. Integrated units fit flush with other cabinets, making integrated refrigeration as practical and beautiful in the master suite, bar or theatre room as in the kitchen.
  • Page 40 Integrated Refrigeration Overall Dimensions 686 mm TALL MODELS 914 mm TALL MODELS 686 mm 610 mm 914 mm 610 mm 356 mm 356 mm 1976 1995 2032 2032 TO TOP OF TO TOP OF OPENNG OPENNG 337 mm 337 mm 260 mm 260 mm 13 mm...
  • Page 41 Integrated Refrigeration subzero.com/specs Overall Dimensions Capacity and Weight DRAWER MODELS Interior Capacity R (L) F (L) 686 mm TALL MODELS 686 mm 610 mm ICB700TR ICB700TCI 914 mm TALL MODELS ICB736TR 337 mm ICB736TCI 686 mm DRAWER MODEL ICB700BR 260 mm Shipping Weight 248 mm ICB700TR and ICB700TCI...
  • Page 42 Integrated Refrigeration Opening Dimensions INTEGRATED MODELS IMPORTANT NOTE: The depth of each integrated model is 610 mm from the front of the unit to its back. Your design may necessitate moving the unit back or cabinets forward to TOP VIEW achieve a flush fit.

  • Page 43: Electrical Requirements

    Integrated Refrigeration subzero.com/specs Electrical Requirements International models from the factory designed without a Electrical Requirements transformer require a 220-240 V AC, 50/60 Hz electrical Power Supply 220-240 V AC, 50/60 Hz supply, fused at the correct rating for the unit. If required Circuit Breaker 10 amp by local or national codes, the power cord can be easily...

  • Page 44: Plumbing Requirements

    64 mm between the supply and the unit. Do not use self-piercing 343 mm valves. A saddle valve kit (4200880) is avail able through your authorized Sub-Zero dealer. 76 mm FLOOR IMPORTANT NOTE: It is critical that the water line be...
  • Page 45 Integrated Refrigeration subzero.com/specs Cabinetry Applications FRAMELESS CABINETRY 679 mm 908 mm PANEL WIDTH PANEL WIDTH 1153 1153 2029 2029 102 mm 4" (102) 686 mm 914 mm FINISHED OPENING FINISHED OPENING 3 mm ALL REVEALS (A) ARE 686 mm MODELS 914 mm MODELS TALL AND DRAWER MODELS TALL MODELS...
  • Page 46 Integrated Refrigeration Cabinetry Applications DOOR PANEL HEIGHT TOE KICK CLEARANCE The height of the door panel can extend beyond the The toe kick clearance can vary with the height of the typical panel height, provided you do not exceed the panel panel.
  • Page 47 Integrated Refrigeration subzero.com/specs Cabinetry Applications Integrated refrigeration is compatible with virtually any IMPORTANT NOTE: The inside edges of the rough opening style and look of cabinetry. These models can be used as well as the sides and a portion of the backside of the with framed as well as frameless cabinetry.

  • Page 48: Dual Installations

    910 mm 424 mm Framed—full overlay. Framed—standard overlay. A dual installation kit is required for installations with 51 mm or less space between the units. Dual installation kits are avail able through your authorized Sub-Zero dealer. UNIT CABINET INTEGRATED CABINET UNIT...
  • Page 49 Accessories These optional accessories are avail able through your STANDARD HANDLES authorized Sub-Zero dealer. For local dealer information, Refer to the chart below for standard handle lengths visit the find a showroom section of our website, and the stud spacing of tubular and pro handles used on subzero.com.
  • Page 50 Integrated Refrigeration INTEGRATED DOOR Maximum Door Opening MAXIMUM 105° OPENING FULL-SCALE TEMPLATE If the panel is thicker than 19 mm, use the built-in 90° door stop to prevent damage to the panel and face frame at the maximum door opening. LINE OF INTERFERENCE 105°...

  • Page 51: Wine Storage

    Wine Storage. Wine finds a well-deserved place of honor in a Sub-Zero wine storage unit. Every detail is designed to ensure better wine preservation. Cherrywood-faced shelves, soft lighting, custom cabinetry if desired—Sub-Zero helps make a wine collection an element of beauty in the home.
  • Page 52 Wine Storage Overall Dimensions UNDERCOUNTER WINE STORAGE 606 mm 610 mm 102 mm 60 mm MODEL ICB424G Overall dimensions are based on stainless steel panels and handles.
  • Page 53 Wine Storage subzero.com/specs Overall Dimensions FULL-SIZE WINE STORAGE 686 mm 610 mm 686 mm 610 mm 356 mm 356 mm 1995 1995 2032 2032 OPENING OPENING HEIGHT HEIGHT 13 mm 13 mm HEIGHT DIMENSIONS ± HEIGHT DIMENSIONS ± DIMENSIONS WILL VARY WITH PANEL THICKNESS DIMENSIONS WILL VARY WITH PANEL THICKNESS MODEL ICB427G MODEL ICB427RG...
  • Page 54 Wine Storage Overall Dimensions Capacity and Weight FULL-SIZE WINE STORAGE Storage Capacity Bottles (750 ml) R (L) ICB424G 762 mm 610 mm ICB427G ICB427RG ICBWS-30 Shipping Weight 2134 ICB424G ICB424FSG ICB427G 1873 ICB427RG ICBWS-30 13 mm HEIGHT DIMENSIONS ± 606 mm 102 mm 60 mm MODEL ICBWS-30...
  • Page 55 Wine Storage subzero.com/specs Opening Dimensions UNDERCOUNTER WINE STORAGE FULL-SIZE WINE STORAGE TOP VIEW TOP VIEW 610 mm 635 mm OPENING OPENING DEPTH DEPTH 610 mm 876 mm 610 mm OPENING DEPTH OPENING OPENING WIDTH HEIGHT 635 mm 2032 mm 686 mm OPENING DEPTH OPENING OPENING WIDTH...

  • Page 56: Model Icbws-30

    Wine Storage Opening Dimensions Planning Information All wine storage models must be installed so that the door FULL-SIZE WINE STORAGE can open a minimum of 90° or you will have problems pulling the wine shelves out. For corner installations, you TOP VIEW need to allow for a minimum 76 mm filler so the door can 610 mm...

  • Page 57: Icb424G

    DUAL INSTALLATIONS Electrical Requirements Power Supply 220-240 V AC, 50/60 Hz If you are installing a wine storage unit next to an existing Sub-Zero unit, you may have to allow for a filler strip. Circuit Breaker 10 amp Receptacle 3-prong grounding-type...

  • Page 58: Icb424G

    Wine Storage Door Panels Overlay Panels Unless you are installing a stainless steel model, you will MODEL ICB424G need to provide a frame for the glass door. If you order a The overlay panel applied to model ICB424G should not stainless steel unit, models ICB424G, ICB424FSG and be confused with the built-in overlay panel application.

  • Page 59: Icb427Rg

    Wine Storage subzero.com/specs Integrated Panels The height of the door panel for models ICB427G and MODELS ICB427G AND ICB427RG ICB427RG can extend beyond the typical panel height, The integrated full panels or frame panels for glass doors provided you do not exceed the panel weight limit. Refer for these models will follow some of the identical planning to specifications on page 46 of the integrated section.
  • Page 60 2235 mm overall height, add 102 mm to height dimensions. Width dimensions do not vary. OVERLAY SPACER SPACER PANEL PANEL PANEL Do not exceed overlay panel dimensions, as this could cause damage to panels and the Sub-Zero unit. OVERLAY PANEL BACKER PANEL BACKER PANEL TRIM DOOR FRAME GLASS...
  • Page 61 Width dimensions do not vary. FLUSH INSET SPACER SPACER PANEL PANEL PANEL FLUSH INSET PANEL Do not exceed flush inset panel dimensions, as this could cause damage to panels and the Sub-Zero unit. BACKER PANEL BACKER PANEL TRIM 8 mm typical Panel assembly cross Panel assembly rear view.
  • Page 62 Contact your Sub-Zero dealer for the proper components and installation instructions. For ques- For additional information on panel reveals, visit the speci- tions relative to the installation, contact your Sub-Zero fication library section of our website, subzerotrade.com.
  • Page 63 211 mm Dual flush inset panels and dual installation kits are avail- Backer Panel 756 mm 227 mm able through your Sub-Zero dealer. Refer to the illustration WINDOW and chart for dual flush inset panel specifications. Cut-Out 584 mm 1581 mm...
  • Page 64 SIDE VIEW SIDE VIEW Do not exceed the flush inset decorative panel dimensions. Exceeding dimensions could cause Illus. C Illus. D damage to the panels and the Sub-Zero unit. DOOR / DRAWER Panel Offsets Illus. MODEL ICBWS-30 Doors (hinge) / Grille Sides...
  • Page 65 MODEL ICBWS-30 be provided. Optional stainless steel tubular and pro When planning for side panels with the installation of the handles are avail able through your authorized Sub-Zero model ICBWS-30, you need to be aware of the space con- dealer.
  • Page 66 Door Frame Profile These optional accessories are avail able through your FULL-SCALE TEMPLATE authorized Sub-Zero dealer. For local dealer information, The full-scale template below shows an example of the visit the find a showroom section of our website, door frame profile for wine storage models and the rela- subzero.com.
  • Page 67 Wine Storage subzero.com/specs Wine Shelf Wood Facing FULL-SCALE TEMPLATE Dimension ICB424G and ICB424FSG 495 mm For each model, the wine storage shelves have a natural ICB427G and ICB427RG 532 mm cherrywood facing. You can replace these strips with ICBWS-30 624 mm wood more complementary to your design and surround- ing cabinetry.

  • Page 68: Door Clearance

    Wine Storage Door Clearance FULL-SCALE TEMPLATE Model ICB424G should extend a minimum of 6 mm beyond the front surface of adjoining cabinetry to allow for the maximum 145° door opening. The unit can be installed flush with adjacent cabinetry, however, there is potential for interference with the panel if the door is opened past 90°.
  • Page 69 SUB-ZERO, INC. P O BOX 44848 MADISON, WI 53744 USA SUBZERO.COM I S Z D G 6 / 2 0 1 0...
