UT-4500 Series C- and Ku-Band Up Converters
Ethernet Interface Operation

7.2.3 SNMP Traps

The DT-45xx SNMP agent supports both SNMPv1 and v2. The Traps
file needs to be compiled only if SNMPv1 traps are to be used.
The UT-4500 has the ability to send out SNMP traps when certain events occur in
the unit. For example, the unit sends out traps when an alarm or a fault occurs
or clears. Which style of traps the UT-4500 sends are configured using the
DT-45xxSNMPTrapVersion OID.
The UT-4500 supports MIB2 SNMPv1 traps and SNMPv2 notifications.

7.3 Telnet Interface

See Chapter 8. SERIAL INTERFACE OPERATION for detailed information
about using remote command and queries.
Figure 7-1. Telnet Interface Example – Windows Command-line
The UT-4500 provides a Telnet interface for equipment M&C via the standard
equipment Remote Control protocol.
Telnet is implemented in the Ethernet M&C in a "Telnet wrapper". When the
user Telnets to the unit, it emulates a local EIA-232C or EIA-485 serial connection
to the unit. You can then type the same command syntax that he would use from
a serial remote terminal and the Ethernet M&C "unwraps" the Telnet packet and
sends it on to the base unit processor, which responds to it as if it was a serial
remote command.
