SBC84820 Pentium M All-In-One Capa Board User's Manual
Designed for the professional embedded developers, the Pentium
embedded board SBC84820 Series is virtually the ultimate one-step
solution for embedded system applications.
1.1

Specifications

CPU
®
LV Intel Pentium
System Chipset
®
Intel 915GME/910GMLE + ICH6M
CPU Frequency
FSB 400 MHz
BIOS
Phoenix-Award BIOS, Y2K compliant
4Mbit Flash, DMI, Plug and Play
SmartView for multiple LCD type selection, display mode
option and application extension features
RPL/PXE Ethernet Boot ROM
"Load Optimized Default" to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
System Memory
One 200-pin DDR2 SO-DIMM socket
Maximum up to 1GB memory
L2 Cache
Integrated in CPU
Onboard IDE
2 channels up to 3 devices (1 parallel ATA-100 and 1
serial ATA-150)
PATA-100 as PIO Mode 0-4, DMA Mode 0-2 and Ultra
DMA/33/66/100
Onboard Serial ATA
Independent DMA operation.
Data transfer rate up to 150 Mbyte/s
2
®
M and ULV Celeron
®
M
®
M processors
Introduction
