2.4.15 FAN Connector (FAN1)

Pentium microprocessors require a fan for heat dispensing. FAN1 is a
fan connector for CPU and system, supplying power to the fan.
Pin
1
2
3
30
Signal
GND
+12V
Sensor
FAN1
Jumpers and Connectors
