CAPA310/313 3.5" Board
1.1

Features

®
CAPA310 - Intel
®
CAPA313 - Intel
N3350 processor (1.1GHz)
1 DDR3L SO-DIMM supports up to 8GB memory capacity
4 USB 3.0 ports and 2 USB 2.0 ports
PCI-Express Mini Cards
+12V~+24V DC-in supported
1.2

Specifications

CPU
CAPA310
®
- Intel
ATOM
CAPA313
®
- Intel
Pentium
®
- Intel
Celeron
Thermal Solution
Passive.
Operating Temperature
CAPA310: -40
CAPA313: -20°C~+70°C.
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
64Mbit SPI Flash, DMI, Plug and Play.
PXE Ethernet Boot ROM.
System Memory
One 204-pin unbuffered DDR3L SO-DIMM socket.
Maximum up to 8GB DDR3L 1867MHz memory capacity.
Note: When the ambient temperature is around 80
thermal solution on DDR3L-1867 module.
Onboard Multi I/O
Serial Ports: One RS-232/422/485 and one RS-232.
Serial ATA
One SATA-600 connector.
mSATA supported.
USB Interface
Four USB 3.0 ports on the rear I/O.
Two USB 2.0 ports in 2x5-pin internal wafer connector.
Display
One 2x20-pin connector for 18/24-bit single/dual channel LVDS and one 8-pin
inverter connector. LVDS resolution is up to 1920x1200 in 24-bit dual channels.
One HDMI supports HDMI1.4b. The resolution is up to 3840x2160.
One 15-pin D-Sub as VGA connector. The resolution is up to 1920x1200 (Optional).
2
®
Atom
quad core x5-E3940 processor (1.6GHz)
®
Pentium
quad core N4200 processor (1.1GHz) and Celeron
®
quad core x5-E3940 1.6GHz.
®
quad core N4200 1.1GHz.
®
dual core N3350 1.1GHz.
o
o
C~+80
C
o
C, it is suggested to add proper
®
dual core
