SBC84600 Series Quick Installation Guide
I.
Checklist
SBC84600 Board x 1
Quick Installation Guide x 1
Product Information CD-ROM x 1
2-pin jumper cap, Pitch=2.54mm x 5
2-pin jumper cap, Pitch=2.0mm x 10
3mm screw nuts x 2
PS/2 Keyboard/Mouse adapter x 1
2.5" & 3.5" HDD cable x 1
Power Cable 8 Pin x 1
If there are damaged or missing parts, contact your supplier
and/or dealer immediately. Do not attempt to apply power to
the board if there is damage to any of its components.
Note: The Windows XP Pro/home SP2 edition is not
supported by VIA non-Nehemiah core version processors
which are adopted by SBC84600VEA/VE-400 and
SBC84600VEA/VE-800. For more information please
http://support.microsoft.com/kb/893356
reference
II.
Jumper Settings
Before turning on the power to the SBC84600 Series,
please make sure that all jumpers are on their default
settings as listed on the table below.
Jumper
Watchdog Trigger Mode: Disabled
JP1
Flat Panel Power Selection: VDDM at 5V
JP2
Clear CMOS Setting: Norma
JP3
COM2 Port Setting: RS-232
JP4
COM2 Port Setting: RS-232
JP5
COM2 Port Setting: RS-232
JP6
Power Supply Selection: AT power supply
JP7
COM1 Signal/+5V Selection
JP8
Default: COM Signal
COM2 Signal/+5V Selection
JP9
Default: COM Signal
©Copyright 2005 AXIOMTEK Co., Ltd.
Version A7 September 2005
Printed in Taiwan
94284600060E
Default Setting
COM+Printer extension cables
with bracket, Pitch=2.0mm x 1
COM extension cables with
bracket, Pitch=2.0mm x 1
FPC cable for extra display
features x 2
Audio Cable x 1 (for
SBC84600VEA Series
Products only)
Jumper Setting
Open
Short 1-2
Short 1-2
Short 1-2
Short 3-5, 4-6
Short 3-5, 4-6
Short 1-2
Short 2-3
Short 2-3
