SBC84820 Pentium

2.3.7

Audio Output Select Jumper (JP9)

This jumper makes the select of Audio output.

Description

Audio Output

Selection

2.3.8

Use this jumper to set Master/Slave CompactFlash interface.

Description

CompactFlash

Master/Slave

Select

Jumpers and Connectors

M All-In-One Capa Board User's Manual

Function

Line Out

(Default)

Speak Out

Function

Slave (Default)

Master

Jumper Setting

JP9

Jumper Setting

JP10
