SBC84820 Pentium
NOTE To disable security, select PASSWORD SETTING
at Main Menu and then you will be asked to enter
password. Do not type anything, just press
<Enter> and it will disable security. Once the
security is disabled, the system will boot and you
can enter Setup freely.
APIC Mode
Use this item to enable or disable APIC (Advanced Programmable
Interrupt Controller) mode that provides symmetric multi-processing
(SMP) for systems.
MPS Version Control For OS
This item specifies the version of the Multiprocessor Specification
(MPS). Version 1.4 has extended configuration tables to improve
support for multiple PCI bus configurations and provide future
expandability.
Small Logo(EPA) Show
If enabled, the EPA logo will appear during system booting up; if
disable, the EPA logo will not appear.
Press <Esc> to return to the Main Menu page.
Award BIOS Utility
®
M All-In-One Capa Board User's Manual
45
