CN8: 7-pin Connector for Inverter
Pin
1
2
3
4
5
6
7
CN6: 40-pin Connector for LVDS Flat Panel
Pin
VCCM
1
VCCM
3
VCCM
5
N.C.
7
GND
9
N.C.
11
N.C.
13
GND
15
Channel B CLK-
17
Channel B CLK+
19
GND
21
Channel A D0-
23
Channel A D0+
25
GND
27
Channel A D1-
29
Channel A D1+
31
GND
33
Channel A D2-
35
Channel A D2+
37
GND
39
CN6
Jumpers and Connectors
®
M All-In-One Capa Board User's Manual
Signal
12V
12V
VCC
BKLT_EN
GND
GND
GND
Signal Pin
VCCM
2
VCCM
4
VCCM
6
N.C.
8
GND
10
Channel B D0-
12
Channel B D0+
14
GND
16
Channel B D1-
18
Channel B D1+
20
GND
22
Channel B D2-
24
Channel B D2+
26
GND
28
N.C.
30
N.C.
32
GND
34
Channel A CLK-
36
Channel A CLK+
38
GND
40
CN8
