SBC84820 Pentium
Normally, you leave this item Disabled. Select Enabled to reset
Extended System Configuration Data (ESCD) when you exit Setup
or if installing a new add-on cause the system reconfiguration a
serious conflict that the operating system can not boot. Options:
Enabled, Disabled.
Resources Controlled By
The Award Plug and Play BIOS can automatically configure all
boot and Plug and Play-compatible devices. If you select Auto, all
interrupt request (IRQ), DMA assignment, and Used DMA fields
disappear, as the BIOS automatically assigns them. The default
value is "Manual".
IRQ Resources
When resources are controlled manually, assign each system
interrupt to one of the following types in accordance with the type
of devices using the interrupt:
1. Legacy ISA Devices compliant with the original PC AT bus
specification, requiring a specific interrupt (such as IRQ4 for serial port
1).
2.
PCI/ISA PnP Devices compliant with the Plug and Play standard,
whether designed for PCI or ISA bus architecture.
The default value is "PCI/ISA PnP"
PCI/VGA Palette Snoop
Some non-standard VGA display cards may not show colors
properly. This item allows you to set whether MPEG ISA/VESA
VGA Cards can work with PCI/VGA or not. When enabled, a
PCI/VGA can work with a MPEG ISA/VESA VGA card; when
disabled, a PCI/VGA cannot work with a MPEG ISA/VESA Card.
** PCI Express relative items **
Maximum Payload Size
When using DDR SDRAM and Buffer size selection, another
consideration in designing a payload memory is the size of the
buffer for data storage. Maximum Payload Size defines the
maximum TLP (Transaction Layer Packet) data payload size for
the device.
Press <Esc> to return to the Main Menu page.
Award BIOS Utility
®
M All-In-One Capa Board User's Manual
.
57
