SBC84820 Pentium
CompactFlash Socket
One CompactFlash Type II Socket jumper selectable as
Master or Slave and DMA mode supported
Power 3.3V (Default) or 5V (Optional)
Onboard Multi-I/O
One floppy port supporting up to one devices (LS-120 or
ZIP Bootable)
One SPP/EPP/ECP parallel port with 26-pin 2.0 pitch box-
header ; supports LS-120
Two 16550 UART-compatible serial ports with +5V/+12V
power output in Pin 1 or Pin 9 via DIP jumper setting.
One RS-232; one RS-232/422/485 and selectable via
jumper setting and auto flow control supported
COM3/4 is optional
USB Interface
Four USB ports with fuse protection and comply with
USB Spec. Rev. 2.0
Real Time Clock
Integrated Intel
Watchdog Timer
255 levels as SMI and Reset from 0 ~ 255 seconds
controlled by W83627HG
Hardware Monitoring
Integrate Winbond W83627HG Super I/O.
Monitoring for CPU/System temperatures,
System Voltage and Chassis/CPU Fan speeds
Graphics/Streaming
VGA On-chip Intel
Supports up to 2048x1536 at 60 Hz resolution on non-
interlaced CRT minitors
Optional Dual LVDS LCD via Chrontel CH7308A transmitter
on the AX93208 stacking board
LCD backlight control supported
18Bits or 36Bits LVDS LCD interface.
Introduction
®
M All-In-One Capa Board User's Manual
®
ICH6M
®
915GME/910GMLE
3
