SBC84820 Pentium

M All-In-One Capa Board User's Manual

Ethernet:

Dual Ethernet

Fast/Gigabit Ethernet; standard for single LAN, 2nd is

Optional from AX93208 stacking Board

Wake On LAN (via ATX power supply)

Equipped with RJ-45 interface

optional Intel 82573V as Gigabit

Audio:

Realtek AC'97 codec audio

Amplify for speaker-out with 2.5W for each channel

MIC-in, Line-in, Line-out/Speaker-out (jumper selectable)

Expansion Slots:

1*140-pin AMP connector for SDVO,

2*PCI Master,

1* PCI-Express and LPC signals

Power Management

ACPI (Advanced Configuration and Power Interface)

Form Factor

3.5" Hard Disk drive form factor

NOTE All specifications and images are subject to change

without notice.
