SBC84820 Pentium

2.3.4

COM1 Mode Select Jumper (JP4)

These jumpers select the COM1 port's DCD and RI mode.

Description

COM1 (JP4)

Jumpers and Connectors

M All-In-One Capa Board User's Manual

Function

*Pin 1=DCD

(Default)

*Pin 1=5V

*Pin 9=RI

(Default)

*Pin 9=+12V

Jumper Setting

JP4
