IMB760 LGA4189 EATX Motherboard
1.1

Features

⚫
Dual Intel® Xeon® Scalable Ice Lake-SP platform up to 270W TDP
⚫ 16 x 288-pin DDR4-3200 RDIMM for up to 1TB of system memory
⚫ 4 PCIe x16, 2 PCIe x8
⚫ Supports two M.2 Key M
⚫ Supports TPM 2.0 (optional)
⚫ IPMI (optional)
⚫ Supports multiple accelerator cards
⚫ Supports internal USB dongle
1.2

Specifications

⚫ CPU
◼ LGA4189 Socket Intel
⚫ Chipset
◼ ®
Intel C627A
⚫
BIOS
◼ AMI BIOS
⚫ System Memory
◼ C627A:
➢
16 x 288-pin DIMM sockets
➢
Maximum 1TB DDR4 R-DIMM memory (max. 64GB per slot)
➢
Supports 3200MHz
➢
Supports the memory with ECC function
⚫ Onboard Multi I/O
◼ 1 x RS-232/422/485 (rear I/O, BIOS selection)
◼ 1 x PS/2 keyboard (internal box header)
⚫ USB Interface
◼ 6 x USB3.1(Gen1) ports (4 x real I/O, 2 x internal box header)
◼
6 x USB 2.0 ports (4 x internal box header, 2 x 180D TypeA)
2
® ®
Xeno Scalable Ice Lake-SP processor
Introduction
