xCommand Camera Preset List

List information about available camera presets.
Note: The xCommand Camera Preset commands are used to store camera positions for individual
cameras. This is in contrast to the xCommand Preset commands where a single preset stores/
recalls ALL connected cameras plus the Video Input switcher settings. This makes it more usable for
integrations where one wants to store multiple camera positions individually per camera rather than a
complete camera position set.
PresetId: Filter on specified preset.
Requires user role: USER
Parameters:
PresetId: <1..35>
Example:
xCommand Camera Preset List PresetId: 1
OK
*r CameraPresetListResult (status=OK)
** end

xCommand Camera Preset Remove

Remove a camera preset.
Note: The xCommand Camera Preset commands are used to store camera positions for individual
cameras. This is in contrast to the xCommand Preset commands where a single preset stores/
recalls ALL connected cameras plus the Video Input switcher settings. This makes it more usable for
integrations where one wants to store multiple camera positions individually per camera rather than a
complete camera position set.
PresetId: The id of the camera preset to remove.
Requires user role: USER
Parameters:
PresetId(r): <1..35>
Example:
xCommand Camera Preset Remove PresetId: 1
OK
*r CameraPresetRemoveResult (status=OK)
** end
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration

xCommand Camera Preset Store

86
xCommand xCommand
Add a new camera preset.
Note: The xCommand Camera Preset commands are used to store camera positions for individual
cameras. This is in contrast to the xCommand Preset commands where a single preset stores/
recalls ALL connected cameras plus the Video Input switcher settings. This makes it more usable for
integrations where one wants to store multiple camera positions individually per camera rather than a
complete camera position set.
PresetId: Optional Id for this preset.
CameraId: Which camera to store the position of.
ListPosition: The sort order of the new preset.
Name: The name that will be used in the listing of presets.
Requires user role: USER
Parameters:
PresetId: <1..35>
CameraId: <1..7>
ListPosition: <1..35>
Name: <S: 0, 255>
Example:
xCommand Camera Preset Store PresetId: 1 CameraId: 1 ListPosition: 1 Name ""
OK
*r CameraPresetStoreResult (status=OK)
** end
