Contents Introduction
xStatus MediaChannels Call [1..n] OutgoingVideoChannel [1..n] Transport RTCP Local
Port
Shows the local UDP port number of the Real-time Transport Control Protocol (RTCP) port for the
outgoing video in the media channel.
Value space of the result returned:
<1..n>
Example:
xStatus MediaChannels Call 27 OutgoingVideoChannel 331 Transport RTCP Local
Port
*s MediaChannels Call 27 OutgoingVideoChannel 331 Transport RTCP Local Port:
16405
** end
xStatus MediaChannels Call [1..n] OutgoingVideoChannel [1..n] Transport RTCP Remote
IpAddress
Shows the remote IP address of the Real-time Transport Control Protocol (RTCP) port for the
outgoing video in the media channel.
Value space of the result returned:
<S: 0, 255>
Example:
xStatus MediaChannels Call 27 OutgoingVideoChannel 331 Transport RTCP Remote
IpAddress
*s MediaChannels Call 27 OutgoingVideoChannel 331 Transport RTCP Remote
IpAddress: "192.168.136.130"
** end
xStatus MediaChannels Call [1..n] OutgoingVideoChannel [1..n] Transport RCTP Remote
Port
Shows the remote UDP port number of the Real-time Transport Control Protocol (RTCP) port for the
outgoing video in the media channel.
Value space of the result returned:
<1..n>
Example:
xStatus MediaChannels Call 27 OutgoingVideoChannel 331 Transport RTCP Remote
Port
*s MediaChannels Call 27 OutgoingVideoChannel 331 Transport RTCP Remote
Port: 50933
** end
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration

The Network status

xStatus Network

xStatus Network 1 Ethernet MacAddress

xStatus Network 1 Ethernet Speed

140
xCommand
Shows the top level overview of the network status.
Example:
xStatus Network
*s Network 1 Ethernet MacAddress: "00:50:60:02:E7:D3"
*s Network 1 Ethernet Speed: "1000full"
*s Network 1 IPv4 Address: "192.0.2.149"
*s Network 1 IPv4 SubnetMask: "255.255.255.0"
*s Network 1 IPv4 Gateway: "192.0.2.10"
*s Network 1 IPv4 DNS Domain Name: "www.example.com www.example.int"
*s Network 1 IPv4 DNS Server 1 Address: "192.0.2.60"
*s Network 1 IPv4 DNS Server 2 Address: "192.0.2.61"
*s Network 1 IPv4 DNS Server 3 Address: ""
*s Network 1 IPv4 DNS Server 4 Address: ""
*s Network 1 IPv4 DNS Server 5 Address: ""
*s Network 1 IPv6 Address: ""
*s Network 1 IPv6 Gateway: ""
*s Network 1 IPv4 MTU: 1500
** end
Shows the MAC (Media Access Control) address for the ethernet interface.
Value space of the result returned:
<S: 0, 100>
Example:
xStatus Network 1 Ethernet MacAddress
*s Network 1 Ethernet MacAddress: "00:50:60:02:FD:C7"
** end
Shows the Ethernet speed in Mbps. The speed can be in full-duplex or half-duplex.
Value space of the result returned:
<10half/10full/100half/100full/1000full>
Example:
xStatus Network 1 Ethernet Speed
*s Network 1 Ethernet Speed: "100full"
** end
