Xconfiguration Provisioning Externalmanager Address; Xconfiguration Provisioning Externalmanager Domain; Xconfiguration Provisioning Externalmanager Path; Xconfiguration Provisioning Externalmanager Protocol - Cisco TelePresence System Codec C90 Reference Manual

Cisco TelePresence System Codec C90
Contents Introduction

xConfiguration Provisioning Password

This is the password part of the credentials used to authenticate the video system with the
provisioning server. This setting must be used when required by the provisioning server. If
Provisioning Mode is Callway, enter the activation code.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
xConfiguration Provisioning Password: ""
Example:

xConfiguration Provisioning HttpMethod

Select the HTTP method to be used for the provisioning.
Requires user role: ADMIN
Value space: <GET/POST>
GET: Select GET when the provisiong server supports GET.
POST: Select POST when the provisiong server supports POST.
Example: xConfiguration Provisioning HttpMethod: POST

xConfiguration Provisioning ExternalManager Address

Enter the IP Address or DNS name of the external manager / provisioning system.
If an External Manager Address (and Path) is configured, the system will send a message to this
address when starting up. When receiving this message the external manager / provisioning system
can return configurations/commands to the unit as a result.
When using CUCM or TMS provisioning, the DHCP server can be set up to provide the external
manager address automatically (DHCP Option 242 for TMS, and DHCP Option 150 for CUCM). An
address set in the Provisioning ExternalManager Address setting will override the setting provided by
DHCP.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: A valid IP address format or DNS name; a compact string with a maximum of 64
characters.
xConfiguration Provisioning ExternalManager Address: ""
Example:
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration

xConfiguration Provisioning ExternalManager Protocol

xConfiguration Provisioning ExternalManager Path

xConfiguration Provisioning ExternalManager Domain

50
xCommand
Determine whether to use secure management or not.
Requires user role: ADMIN
Value space: <HTTP/HTTPS>
HTTP: Set to HTTP to disable secure management. Requires HTTP to be enabled in the
xConfiguration NetworkServices HTTP Mode setting.
HTTPS: Set to HTTPS to enable secure management. Requires HTTPS to be enabled in the
xConfiguration NetworkServices HTTPS Mode setting.
Example: xConfiguration Provisioning ExternalManager Protocol: HTTP
Set the Path to the external manager / provisioning system. This setting is required when several
management services reside on the same server, i.e. share the same External Manager address.
ADMIN
Requires user role:
Value space: <S: 0, 255>
Format: String with a maximum of 255 characters.
Example: xConfiguration Provisioning ExternalManager Path: "tms/public/
external/management/SystemManagementService.asmx"
Enter the SIP domain for the VCS provisioning server.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
xConfiguration Provisioning ExternalManager Domain: "any.domain.com"
Example:
API Reference Guide
xStatus Appendices
www.cisco.com
