xConfiguration Video Output HDMI [1, 3] CEC Mode

The HDMI outputs support Consumer Electronics Control (CEC). When set to on (default is off), and
the monitor connected to the HDMI output is CEC compatible and CEC is configured, the system will
use CEC to set the monitor in standby when the system enters standby. Likewise the system will wake
up the monitor when the system wakes up from standby. Please note that the different manufacturers
uses different marketing names for CEC: Anynet+ (Samsung); Aquos Link (Sharp); BRAVIA Sync
(Sony); HDMI-CEC (Hitachi); Kuro Link (Pioneer); CE-Link and Regza Link (Toshiba); RIHD (Onkyo);
SimpLink (LG); HDAVI Control, EZ-Sync, VIERA Link (Panasonic); EasyLink (Philips); and NetCommand
for HDMI (Mitsubishi).
Requires user role: ADMIN
Value space: <On/Off>
On: Enable CEC control.
Off: Disable CEC control.
Example: xConfiguration Video Output HDMI 1 CEC Mode: Off

xConfiguration Video Output HDMI [1, 3] MonitorRole

The HDMI monitor role describes what video stream will be shown on the monitor connected to the
video output HDMI connector. Applicable only if the monitor configuration is set to dual or quadruple.
ADMIN
Requires user role:
<First/Second/PresentationOnly/Third/Fourth>
Value space:
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Third: Use for remote participants (only for quadruple monitor setup).
Fourth: Use for remote participants (only for quadruple monitor setup).
Example: xConfiguration Video Output HDMI 1 MonitorRole: First

xConfiguration Video Output HDMI [1, 3] OverscanLevel

Some TVs or other monitors may not display the whole image sent out on the systems video output,
but cuts the outer parts of the image. In this case this setting can be used to let the system not use
the outer parts of video resolution. Both the video and the OSD menu will be scaled in this case.
Requires user role: ADMIN
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
xConfiguration Video Output HDMI 1 OverscanLevel: None
Example:
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration

xConfiguration Video Output HDMI [1, 3] Resolution

xConfiguration Video Output DVI [2, 4] MonitorRole

xConfiguration Video Output DVI [2, 4] OverscanLevel

63
xCommand
Select the preferred resolution for the monitor connected to the video output HDMI connector. This
will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <Auto/640 _ 480 _ 60/800 _ 600 _ 60/1024 _ 768 _ 60/1280 _ 1024 _ 60/1280 _ 72
0 _ 50/1280 _ 720 _ 60/1920 _ 1080 _ 50/1920 _ 1080 _ 60/1280 _ 768 _ 60/1360 _ 768 _ 60/136
6 _ 768 _ 60/1600 _ 1200 _ 60/1920 _ 1200 _ 60>
Auto: The system will automatically try to set the optimal resolution based on negotiation with the
connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@50p,
1280x720@60p, 1920x1080@50p, 1920x1080@60p, 1280x768@60p, 1360x768@60p,
1366x768@60p, 1600x1200@60p, 1920x1200@60p
Example: xConfiguration Video Output HDMI 1 Resolution: 1920 _ 1080 _ 60
The DVI monitor role describes what video stream will be shown on the monitor connected to the
video output DVI-I connector. Applicable only if the monitor configuration is set to dual or quadruple.
ADMIN
Requires user role:
<First/Second/PresentationOnly/Third/Fourth>
Value space:
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Third: Use for remote participants (only for quadruple monitor setup).
Fourth: Use for remote participants (only for quadruple monitor setup).
Example: xConfiguration Video Output DVI 4 MonitorRole: First
Some TVs or other monitors may not display the whole image sent out on the systems video output,
but cuts the outer parts of the image. In this case this setting can be used to let the system not use
the outer parts of video resolution. Both the video and the OSD menu will be scaled in this case.
Requires user role: ADMIN
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
xConfiguration Video Output DVI 2 OverscanLevel: None
Example:
