xConfiguration Audio Input Line [1..4] Equalizer ID
Select the audio input line equalizer ID.
Requires user role: ADMIN
Value space: <1..8>
Range: Select EqualizerID 1 to 8.
xConfiguration Audio Input Line 1 Equalizer ID: 1
Example:
xConfiguration Audio Input Line [1..4] Equalizer Mode
Set the audio input line equalizer mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the equalizer for the audio input line.
Off: No equalizer.
Example: xConfiguration Audio Input Line 1 Equalizer Mode: Off
xConfiguration Audio Input Line [1..4] VideoAssociation MuteOnInactiveVideo
Enable association of a video source to a Line audio input.
Requires user role: ADMIN
Value space: <On/Off>
On: A video source is associated, and the audio will be muted if the associated video source is not
displayed.
Off: No video source is associated.
Example: xConfiguration Audio Input Line 1 VideoAssociation
MuteOnInactiveVideo: Off
xConfiguration Audio Input Line [1..4] VideoAssociation VideoInputSource
Select the associated video input source.
Requires user role: ADMIN
Value space: <1/2/3/4/5>
Range: Select one of the video input sources.
xConfiguration Audio Input Line 1 VideoAssociation VideoInputSource: 1
Example:
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration
xConfiguration Audio Input Line [1..4] Channel
xConfiguration Audio Input Line [1..4] Level
xConfiguration Audio Input Line [1..4] LoopSuppression
xConfiguration Audio Input Line [1..4] Mode
30
xCommand
Define whether the Audio Line input is a mono signal or part of a multichannel signal.
Requires user role: ADMIN
Value space: <Left/Right/Mono>
Left: The Audio Line input signal is the left channel of a stereo signal.
Right: The Audio Line input signal is the right channel of a stereo signal.
Mono: The Audio Line input signal is a mono signal.
xConfiguration Audio Input 1 Channel: Left
Example:
Define the audio level of the Line input connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview of
the menu values represented in dB.
Requires user role: ADMIN
Value space: <0..24>
Range: Select a value from 0 to 24 dB.
Example: xConfiguration Audio Input Line 1 Level: 10
The loop suppression functionality detects whether a delayed signal loop is present from an audio
Line output to an audio Line input on the codec. If a loop is detected the unwanted feedback is
suppressed.
NOTE: Only loops between line output 3 and line input 3, and between line output 4 and line input 4
are suppressible.
ADMIN
Requires user role:
<On/Off>
Value space:
On: Activate Loop Suppression.
Off: Deactivate Loop Suppression.
xConfiguration Audio Input Line 3 LoopSuppression: On
Example:
Set the audio input line mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the Audio Line input.
Off: Disable the Audio Line input.
xConfiguration Audio Input Line 1 Mode: On
Example:
