Cisco TelePresence System Codec C90
Contents Introduction

xConfiguration Experimental Audio MicrophoneReinforcement Gain

NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Microphone reinforcement is local amplification of one or several input connectors, directly to one or
several output connectors, with minimum delay.
For software version TC4.0: Microphone reinforcement should not be enabled on a codec that is also
configured using the Audio Console application.
This setting configures the gain of this path, from -53 dB to +15 dB. The value -54 corresponds to
mute.
Requires user role: ADMIN
Value space: <-54..15>
xConfiguration Experimental Audio MicrophoneReinforcement Gain: -19
Example:

xConfiguration Experimental Audio MicrophoneReinforcement AGC

NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Microphone reinforcement is local amplification of one or several input connectors, directly to one or
several output connectors, with minimum delay.
For software version TC4.0: Microphone reinforcement should not be enabled on a codec that is also
configured using the Audio Console application.
This setting controls an AGC on the mix of all input connectors attached to the Microphone
reinforcement.
ADMIN
Requires user role:
<On/Off>
Value space:
Example: xConfiguration Experimental Audio MicrophoneReinforcement AGC: Off

xConfiguration Experimental Audio MicrophoneReinforcement Input Microphone [1..8]

Mode
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Microphone reinforcement is local amplification of one or several input connectors, directly to one or
several output connectors, with minimum delay.
For software version TC4.0: Microphone reinforcement should not be enabled on a codec that is also
configured using the Audio Console application.
Configuring this setting to On for a microphone, means to attach it to the microphone reinforcement
for local amplification. This is done in parallel to the microphone's existing connections, and will not
affect any of these.
ADMIN
Requires user role:
<On/Off>
Value space:
xConfiguration Experimental Audio MicrophoneReinforcement Input
Example:
Microphone 1 Mode: On
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration

xConfiguration Experimental Audio MicrophoneReinforcement Output Line [1..6] Mode

xConfiguration Experimental AudioTracking Camera [1..7] Mode

xConfiguration Experimental BrightnessGradient Camera [1..7] Mode
66
xCommand
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Microphone reinforcement is local amplification of one or several input connectors, directly to one or
several output connectors, with minimum delay.
For software version TC4.0: Microphone reinforcement should not be enabled on a codec that is also
configured using the Audio Console application.
Configuring this setting to On for an output line, means to attach that output connector to the
microphone reinforcement for local amplification. If the output connector already is attached
to a Local Output, it will first be detached from that before being attached to the Microphone
reinforcement. When this setting is On, the output connector cannot be attached to any Local Output.
Requires user role: ADMIN
Value space: <On/Off>
Example: xConfiguration Experimental Audio MicrophoneReinforcement Output Line
1 Mode: On
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <On/Off>
Example: xConfiguration Experimental AudioTracking Camera 1 Mode: Off
NOTE: The Experimental settings can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
NOTE: Applies to Cisco TelePresence T1/T3. This settings can be configured from the command line
interface, and not from the menu.
Requires user role: ADMIN
<On/Off>
Value space:
On: Enable row dependent digital gain.
Off: Disable row dependent digital gain.
xConfiguration Experimental BrightnessGradient Camera 1 Mode: Off
Example:
API Reference Guide
xStatus Appendices
